MSC ADAMS Based Simulation of a Test-Bed for Cell Injecting Using IPMC

Abstract:

The research is aimed at finishing the dynamic simulation of test-bed for cell injecting using IPMC (Ionic Polymer Metal Composites) based on MSC ADAMS. By changing experiment data of the simulation in ADAMS, researchers choose optimization data as the initial parameters of test-bed for cell injecting. A multi-rigid-body system dynamics model of the test-bed for cell injecting is established through analyzing the system dynamic parameters and applying a mechanical dynamic analysis software ADAMS. The optimal PID parameters of microscope’s focusing system are confirmed. Thus relevant actuating motor can control microscope’s lens rapidly and exactly by these parameters. The realization of ordinal simulation provides accurate recognition of experiment system’s initial position and running time. This research finishes dynamic simulation and analysis of a test-bed for cell injecting using ADAMS software. Optimal parameters are chosen for the control system according to simulation and analysis. The theoretical analysis and experimental results can be widely referred by the multi-rigid-body physical prototype manufacture.

• Periodical: Advanced Engineering Forum (Volumes 2-3)
• Pages: 507-511
• DOI: https://doi.org/10.4028/www.scientific.net/AEF.2-3.507
• Online since: December 2011
• Authors: Li Na Hao, Hong Tao Liu, Jian Chao Gao, Peng Zhang
• Keywords: Analysis, Cell Injecting, Dynamic Simulation, Optimization Design, PID, Smart Materials, Virtual Prototype

References

[1] HAO Li-na, Gao Jian-chao, LIU Hong-tao. A Novel Determination Method of IPMC Young's Modulus based on Cantilever Resonance Theory, C. 2011 International Conference on Mechanical Materials and Manufacturing Engineering. Nanchang, 2011: 747-752.

DOI: 10.4028/www.scientific.net/amm.66-68.747

[2] Byungkyo K，Jaewook R，Younkoo J，et al．A Ciliary Based 8-Legged Walking Micro Robot Using Cast IPMC Actuators, C. Proceedings of the 2003 IEEE International Conference on Robotic & Automation．Taipei，2003：14-19.

DOI: 10.1109/robot.2003.1242042

[3] Thanh T，Vinh K，Youngtai Y，et al．A Novel Polymeric Micropump based on a Multilayered Ionic Polymer-Metal Composite, C. IEEE Industrial Electronics, IECON 2006-32nd Annual Conference on．Paris ，2006：4888-4893.

DOI: 10.1109/iecon.2006.347352

[4] Hao Li-na, Xu Su, Liu Bin. A Miniature Fish-like Robot with Infrared Remote Receiver and IPMC Actuator ,J. Journal of Northeastern University (Natural Science), 2009, 30(6): 773-776).

[5] Bai Li-ping. Simulation analysis of robot dynamics based on ADAMS, J. Robot Technology, 2007, 7: 1001-4551.

[6] Rui Zhi-yuan, Wei Xing-chun, Feng Rui-cheng. Virtual prototyping technology based on ADAMS and its application in mechanism design, J. Science Technology and Engineering, 2006, 6 (19) : 3111 - 3114.

[7] NOEL O. Use of ADAMS in Dynamics Simulation of Landing Gear Retraction and Extension, C. 13th European ADAMS User's Conference. France: [s, n], 1998: 1 - 8.

[8] Ran Xian-bin. Design of microforce sensor based on IPMC. School of Mechanical Engineering & Automation, Northeastern University, Shenyang, (2010).
