Structural Response of Sandwich Beams with Different Facing Materials Subjected to Bending

Abstract:

Sandwich elements with structural functions are widely used in engineering applications, offering outstanding advantages, such as high strength and stiffness compared to its low specific weight. The sandwich elements consist in two stiff and thin faces, separated by a thick and lightweight core. A numerical analysis is performed in this paper, in order to evaluate the flexural structural response of sandwich beams with foam core and various facing materials. It has been noticed that the deflections decrease when the stiffness of the facings increase. The results are represented in terms of maximum deflections and direct stress distributions.

• Periodical: Advanced Engineering Forum (Volume 21)
• Pages: 294-300
• DOI: https://doi.org/10.4028/www.scientific.net/AEF.21.294
• Online since: March 2017
• Authors: Iuliana Dupir*, Nicolae Ţăranu, Cristina Vlădoiu, Dragoş Ungureanu, Vlad Lupăşteanu
• Keywords: Deflection, Direct Stresses, Facings, Flexural Response, Sandwich Beams

References

[1] N. Țăranu, Bearing elements made of plastic materials, Ph.D. thesis, written in romanian, Polytechnical Institute Gh. Asachi, of Iasi, (1978).

[2] M.Z. Hassan, Z.W. Guan, W.J. Cantwell, G.S. Langdon, G.N. Nurick, The influence of core density on the blast resistance of foam-based sandwich structures, Int. J. Impact Eng 50 (2012) 9-16.

DOI: 10.1016/j.ijimpeng.2012.06.009

[3] H. Lei, K. Yao, W. Wen, H. Zhou, D. Fang, Experimental and numerical investigation on the crushing behavior of sandwich composite under edgewise compression loading, Compos. Part B-Eng. 94 (2016) 34-44.

DOI: 10.1016/j.compositesb.2016.03.049

[4] X. Wang, Y. Wang, Static analysis of sandwich panels with non-homogeneous soft-cores by novel weak form quadratures element method, Compos. Struct. 146 (2016) 207-220.

DOI: 10.1016/j.compstruct.2016.03.017

[5] C. Lainé, P. Le Grognec, S.C. Cardona, C. Binetruy, Analytical, numerical and experimental study of the bifurcation and collapse behaviour of a 3D reinforced sandwich structure under through-thickness compression, Int. J. Mech. S. 67 (2013) 42-52.

DOI: 10.1016/j.ijmecsci.2012.12.005

[6] D. Zenkert, An Introduction to Sandwich Construction, Chameleon Press Ltd., London, (1995).

[7] N. Pokharel, M. Mahendran, Finite element analysis and design of sandwich panels subject to local buckling effects, Thin Wall Struct 42 (2004) 589-611.

DOI: 10.1016/j.tws.2003.08.002

[8] H.G. Allen, Analysis and design of structural sandwich panels, Pergamon Press, Oxford, (1969).

[9] C. Marta, Multicriterial optimization of cladding elements for industrial buildings, Ph.D. thesis, written in romanian, Gh. Asachi, Technical University of Iasi, (2007).

[10] I. Hudișteanu, N. Țăranu, I. -S. Ențuc, S.G. Maxineasa, Comparative analysis of the engineering constants of composite laminates, Rev. Rom. Mat. 2 (2016) 232-241.

[11] ANSYS® Static Structural, Engineering Data Sources, ANSYS, Inc.

[12] I. Dupir (Hudișteanu), N. Țăranu, C. Vlădoiu, Direct stresses on layers of the sandwich beam with foam core, Bulletin of the Polytechnic Institute of Jassy, Construction. Architecture Section LX (LXIV) 3 (2014) 99-108.
