Automatic Current Balance for Multi-Phase Switching Converters with Ripple Control or Soft Switch

Abstract:

This paper proposes a new multi-phase switching converter with atuotomatic current barance technique. It is well-known that the multi-phase switching converter is suitable to handle large output current with small output voltage ripple for the buck converters which use the clock pulse. This paper investigates a multi-phase controlled method for the ripple-controlled converters and the soft switching converters, that use no clock pulse; for this reason, these converters are difficult to realize multi-phase converter configurations. There are some multi-phase hysteretic controlled converters; they utilize a main clock generator or an external sub-clock pulse, which has the master-slave synchronization method. But it is difficult to respond to a frequency change of the master converter. These multi-phase converters have not considered the imbalance among phase currents caused by variations of inductors and semiconductor switches in the power stage. For the commercialized multi-phase Voltage Regulating Modules (VRMs), the inductors and the semiconductor switches are selected to adjust the balance among the phase currents. However, there is no multi-phase soft switching converter.Then we have developed the multi-phase ripple-controlled converter and the multi-phase soft switching converter with the technique of detecting 180-degree from the variable operating frequency of the main converter. Moreover, in these converters, there appears the current imbalance because of the element variations among inductors and capacitors, if some cares are not taken there. Then we have developed the automatic correction for the current imbalance by modifying the width of the Constant On Time (COT) pulse or modifying the slope of the saw-tooth signal.

• Periodical: Advanced Engineering Forum (Volume 38)
• Pages: 143-156
• DOI: https://doi.org/10.4028/www.scientific.net/AEF.38.143
• Online since: November 2020
• Authors: Yasunori Kobori*, Jing Li, Yi Fei Sun, Minh Tri Tran, Anna Kuwana, Haruo Kobayashi
• Keywords: Current Balance Correction, Multi-Phase Switching Converter, Ripple-Controlled Converter, Soft Switching Converter

References

[1] R.W. Erickson, D. Maksimovic, Principles of Steady-State Converter Analysis,, in Fundamentals of Power Electronics, Kluwer Academic Publishers, Netherlands (2004).

[2] H. Kobayashi, T Nabeshima, Control Schemes of Switching Converters, in Handbook of Power Management Circuits, Pan Stanford Publishers, USA (2016).

[3] W. Huang, A New Control for Multi-Phase Buck Converter with Fast Transient Response, IEEE Applied Power Electronics Conference, Anaheim, CA (1998).

DOI: 10.1109/apec.2001.911660

[4] G. Schrom, P. Hazucha, J. Hahn, D.S. Gardner, B.A. Bloechel, G. Dermer, S.G. Narendra, T. Karnik, V. De, A 480-MHz. Multi-Phase Interleaved Buck DC-DC Converter with Hysteretic Control,, IEEE Power Electronic Specialists Conference, Aachen, Germany (2004).

DOI: 10.1109/pesc.2004.1354830

[5] J.A. Abu-Qahoug, N. Pongratananukul, I. Batarseh, T. Kasparis, Multiphase Voltage-mode Hysteretic Controlled VRM with DSP Control and Novel Current Sharing,, IEEE International Caracas Conference on Devices, Circuits and Systems, Oranjestad, Aruba, Netherlands (2002).

DOI: 10.1109/iccdcs.2002.1004098

[6] T. Sato, T. Nabeshima, K. Nishijima, T. Nakano, Multi-Phase Converter Controlled by Hysteretic PWM Method,, IEEE Power Conversion Conference, Nagoya, Japan (April 2007).

DOI: 10.1109/pccon.2007.373108

[7] Y. Xiong, Y. Sun, N. Tsukiji, Y. Kobori, H. Kobayashi, Two-Phase Soft-Switching DC-DC Converter with Voltage-mode Resonant Switch,, IEEE International Symposium on Intelligent Signal Processing and Communication System, Xiamen, China (Nov. 2017).

DOI: 10.1109/ispacs.2017.8266573

[8] J. Li, Y. Xiong, Y. Sun, Y. Kobori, A. Kuwana, H. Kobayashi, Automatic Correction of Current Imbalance due to Element Variations in Multi-Phase Ripple Controlled Converter,, Institute of Electronics, Information and Communication Engineers (IEICE), Energy Engineering in Electronics and Communications (EE), Tokyo, Japan (May. 2019).

DOI: 10.1109/asicon47005.2019.8983672

[9] S. Katayama, J. Li, Y. Sun, M. T. Tran, Y. Kobori, A. Kuwana, H. Kobayashi, Automatic Current Balancing Circuit for Multi-Phase Constant-ON Time Hysteresis Control Converter,, The 5th Taiwan and Japan Conference on Circuits and Systems (TJCAS 2019), Nikko, Japan (Aug. 2019).

DOI: 10.1109/asicon47005.2019.8983672

[10] C. Zhang, Y. Sun, T. M. Tri, Y. Kobori, A. Kuwana, H. Kobayashi, Current Balancing Circuit for Multi-Phase Full/Half Wave Resonant Converter,, The 5th Taiwan and Japan Conference on Circuits and Systems (TJCAS 2019), Nikko, Japan (Aug. 2019).

DOI: 10.1109/asicon47005.2019.8983590
