Reinforcing the Bridges in Tunnel Excavation Region by Using a Method Combining Jacking Superstructure and Grouting Substructure

Abstract:

It is crucial to alleviate the effect of construction of underground transportation on the safety of the bridges in tunnel excavation region since it is inevitable for the tunnel to go across the city viaduct. To solve above problem, a technique of bridge reinforcement was proposed, which combines the jacking superstructure of bridges and grouting substructure. With this technique, the uneven settlement of the bridge foundation could be controlled as well as the change of the upper structure of bridges could be limited in a reasonable interval. Finally, the effectiveness of proposed method is demonstrated by reinforcing a real bridge in the region of subway construction in Guangzhou, China.

• Periodical: Advanced Engineering Forum (Volume 5)
• Pages: 162-166
• DOI: https://doi.org/10.4028/www.scientific.net/AEF.5.162
• Online since: July 2012
• Authors: Bao Jin, Yang Liu
• Keywords: Bridge Engineering, Bridge Reinforcement, Grouting Technique, Jack-Up Technique, Tunnel Engineering

References

[1] G.Q. Sun, Down through the tunnel building protection scheme selection and grouting test plan, Journal of railway engineering, 2010,144 (9):35-40. (in Chinese)

[2] L. Li, The protection scheme discusses of the building foundation subway tunnel through, Tunnel construction, 2008, 28 (6):720-723. (in Chinese)

[3] Z.M. Zhang, Q.Q. Zhang, The test research about post-grouting compressive pile mechanical properties, Journal of rock mechanics and engineering, 2009, 28 (3): 476-482. (in Chinese)

[4] F.R. Xu, Q.Q. Li, The application of sleeve valve barrel grouting consolidation in the viaduct pile foundation of the protection, Modern urban rail traffic, 2010:33-37. (in Chinese)

[5] JGJ 94-2008, Building pile foundation technical specifications, Beijing, 2008. (in Chinese)
