Numerical Simulation and Experimental Investigation on Thixo-Backward Extrusion of 7075 Aluminium Alloy

Abstract:

The thixoextrusion process could become an important technique to extend the complexity of extruded profiles. However, the complex thixotropic flow behavior of semi-solid, during thixoextrusion is still partly characterized. The study described in this paper investigates thixoextrusion for 7075 aluminium alloy at different temperature conditions. A complete die filling and a good surface state of parts was obtained at high solid fraction (f_S = 0.70), in heated dies, for an extrusion ram speed of 416 mm/s. The thixoextrusion process is simulated using the finite element code Forge2009©. The constitutive equation used for these simulations is based on a micro-macro model for the semi-solid evolution. The tendency of the experimental curves evolution, preserving the same parameters of the micro-macro constitutive model, for each values of solid fraction, was reproduced, except the last step of the ram displacement.

• Periodical: Advanced Engineering Forum (Volumes 8-9)
• Pages: 269-276
• DOI: https://doi.org/10.4028/www.scientific.net/AEF.8-9.269
• Online since: June 2013
• Authors: Adriana Neag, Véronique Favier, Liviu Nistor, Régis Bigot
• Keywords: 7075 Aluminum Alloy, Numerical Simulation, Semi-Solid, Thixoextrusion

References

[1] Kirkwood, D.H., Sellars, C.M., Elias-Boyed, L.G., 1992. Thixotropic materials. European Patent No. 0305375 B1.

[2] S. Chayong, H.V. Atkinson, P. Kapranos, Thixoforming 7075 aluminium alloys, Materials Science and Engineering A 390 (2005) 3–12.

DOI: 10.1016/j.msea.2004.05.004

[3] Li Yuan-dong, Apelian Diran, Xing Bo, Ma Ying, Hao Yuan, Commercial Am60 alloy for semisolid processing: I alloy optimization and thermodynamic analysis, 11th Int. Conf. on semi-solid processing of alloys and composites (2010) 29-35.

DOI: 10.1016/s1003-6326(09)60341-1

[4] D. Larouche, C. Laroche, M. Bouchard, Analysis of differential scanning calorimetric measurements performed on a binary aluminium alloy, Acta Materialia 51 (2003) 2161–2170.

DOI: 10.1016/s1359-6454(03)00003-x

[5] G. Vaneetveld, A. Rassili, H.V. Atkinson, Influence of parameters during induction heating cycle of 7075 aluminium alloys with RAP process, Solid State Phenomena Vols. 141-143 (2008) 719-724.

DOI: 10.4028/www.scientific.net/ssp.141-143.719

[6] A. Bolouri, M. Shahmiri, C.G. Kang, Study on the effects of the compression ratio and mushy zone heating on the thixotropic microstructure of AA 7075 aluminum alloy via SIMA process, Journal of Alloys and Compounds Vol. 509/ 2, (2011), 402–408.

DOI: 10.1016/j.jallcom.2010.09.042

[7] M. Suery, Mise en forme des alliages métalliques à l'état semi-solide. Traité MIM Mecanique et Ingénierie des Matériaux, Ed. Lavoisier, (2002).

DOI: 10.51257/a-v1-m3050

[8] A. Neag, V. Favier, R. Bigot, M. Pop, Microstructure and flow behaviour during backward extrusion of semi-solid 7075 aluminium alloy, J. Mat. Proces. Tech. 212 (2012) 1472– 1480.

DOI: 10.1016/j.jmatprotec.2012.02.003

[9] A. Neag, V. Favier, M. Pop, E. Becker, R. Bigot, Effect of Experimental Conditions on 7075 Aluminium Response During Thixoextrusion, Key Engineering Materials Vols 504–506 (2012) 345-350.

DOI: 10.4028/www.scientific.net/kem.504-506.345

[10] Bolouri, A., Shahmiri, M., Cheshmeh, E.N.H., Microstructural evolution during semisolid state strain induced melt activation process of aluminium 7075 alloy, Trans. Nonferrous Met. Soc. China 20 (2010), 1663-1671.

DOI: 10.1016/s1003-6326(09)60355-1

[11] Q. CHEN , G. ZHAO, D. Shu, Study on microstructural evolution of deformed magnesium alloy during partial remelting, Solid State Phenomena Vols. 192-193 (2013) 246-250.

DOI: 10.4028/www.scientific.net/ssp.192-193.246

[12] A. Neag, E. Becker, M. Pop, E. Henrion, R. Bigot, Influence of Experimental Conditions on Material Response During Thixoextrusion Process, ACTA TECHNICA NAPOCENSIS - Series: Applied Mathematics and Mechanics No. 54, Vol. II, (2011).

[13] E. Becker, R. Bigot, L. Langlois, Thermal exchange effects on steel thixoforming processes, Int. J. Adv. Manuf. Technol. (2010) 48: 913–924.

DOI: 10.1007/s00170-009-2353-8

[14] V. Favier, P. Cézard, R. Bigot, Transient and non-isothermal semi-solid behaviour: 3D micromechanical modelling, Materials Science and Engineering A 517 (2009) 8–16.

DOI: 10.1016/j.msea.2009.03.018
