Testing and Analysis of High-Speed Camera for Pulse MIG/MAG Welding Droplet Transition

Abstract:

The droplet transition of electrical arc welding is a complicated process that combines heat, mass and momentum transfer. A high-speed camera system with laser in the background is established to observe the fast changing process of droplet transition. A group of high-speed camera pictures which indicate that the size and shape of droplet have strong uncertainty are taken and analyzed. The results show that the randomness of droplet size and shape are decided by its internal and external random factors, such as: the changing of the length of welding wire stretched out, the fluctuation of the feed speed of welding wire etc.

• Periodical: Applied Mechanics and Materials (Volume 103)
• Pages: 134-137
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.103.134
• Online since: September 2011
• Authors: Yuan Mei Wen, Shi Sheng Huang, Gui Xiong Liu
• Keywords: Droplet Transfer, Electric Arc Welding, High Speed Camera, Uncertainty

References

[1] H. Li, G.H. Li and J.Y. Li: China Mechanical Engineering, Vol. 13(2002), P. 797.

[2] Z.H. Wang, L.P. Jiang and X.D. Jiao: Laser Journal, Vol. 27(2006), P. 67.

[3] S.S. Huang, Y.M. Wen and J.X. Xue: Journal of South China University of Technology (Natural Science Edition), Vol. 36(2008): P. 2.

[4] Z.M. Liu, M.L. Li and L. Xue: Laser & Infrared, Vol. 36(2006): P. 132.

[5] C.D. Allemand, R. Schoeder and D.E. Ries: Welding Journal, Vol. 64(1985):P. 46.

[6] S.X. Zhang, M. Yao and W.P. Sun: High-speed video and applied technology. Defense Industry publications, China 2006).

[7] Y.M. Wen, S.S. Huang and J.X. Xue: Transactions of the china welding institution, Vol. 29(2008): P. 15.

[8] Y.M. Wen, S.S. Huang and K.Y. Wu: Transactions of the china welding institution, Vol. 31(2010): P. 18.

[9] Z.M. Zhu, W.K. Wu and Q. Chen: Transactions of the china welding institution, Vol. 27(2006): P. 29.
