Wheel-Rail Contact Point Calculation of Flexible Wheelset Base on Wheel-Rail Contact Line Method

Abstract:

Elastic deformation of wheelset should be considered for wheelset dynamic research. In this article, a new wheel-rail contact point searching algorithm that can be used for flexible wheelset simulation was developed based on wheel-rail contact line method. For given position and deformation of wheelset, normal vectors of a point on each rolling circle and its project on rail were calculated to find out possible contact point, which formed wheel-rail contact line. The final contact point was determined by minimum vertical distance of contact line and rail section profile. Rigid-flexible coupling dynamic equations of single wheelset were established and dynamic simulation was executed. The impact of wheelset deformation on wheel-rail contact position and creepage were discussed. Comparison of rigid and flexible wheelset results show that the new method gets more accurate contact point position.

• Periodical: Applied Mechanics and Materials (Volumes 105-107)
• Pages: 1284-1288
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.105-107.1284
• Online since: September 2011
• Authors: Hao Gao, Huan Yun Dai
• Keywords: Contact Line, Creepage, Flexible Wheelset, Wheel-Rail Contact Point

References

[1] L. Baeza, J. Fayos ,A. Roda, R. Insa. High frequency railway vehicle-track dynamics through flexible rotating wheelsets. Vehicle System Dynamics. Vol. 46: 7(2008), pp.647-659.

DOI: 10.1080/00423110701656148

[2] K. Popp,I. Kaiser,H. Kruse. System dynamics of railway vehicles and track. Archive of Applied Mechanics. Vol. 72(2003), p.949–961.

DOI: 10.1007/s00419-002-0261-6

[3] KAISER INGO, POPP KARL. Interaction of Elastic Wheelsets and Elastic Rails: Modeling and Simulation [J]. Vehicle System Dynamics, Vol. 44, (2006) , pp.932-939.

DOI: 10.1080/00423110600907675

[4] JURGEN ARNOLD, INGO KAISER, GUNTER SCHUPP. Simulation of a Railway Vehicle's Runing Behaviour: How Elastic Wheelsets Influence the Simulation Results. Vehicle System Dynamic Supplement, Vol. 41(2004), pp.242-251.

[5] Wang Kaiwen. The Track of Wheel Contact Points and the Calculation of Wheel-rail Geometric Contact Parameters (in Chinese). Journal of Southwest Jiaotong University. Vol. 1(1984), pp.89-99.

[6] Kalker, J. J. Three-Dimensional Elastic Bodies in Rolling Contact, Solid mechanics and its application, Kluwer Academic Publishers, Dordrecht/Boston/London, Vol. 2, (1990).

DOI: 10.1007/978-94-015-7889-9

[7] M.A. Brownand A.A. Shabana. Application of multibody methodology to rotating shaft problems, J. Sund Vib. Vol. 204(1997), p.439–457.

[8] Ahmed A. Shabana. DYNAMICS OF MULTIBODY SYSTEMS. University of Illinois at Chicago. Cambridge University Press, (2005).

[9] Rami Al Nazer. Flexible Multibody Simulation Approach in the Dynamic Analysis of Bone Strains during Physical Activity. Lappeenranta, (2008).
