Analysis of Dynamic Characteristics of the Magnetostrictive Power Ultrasonic Transducer

Abstract:

The giant magnetostrictive material (GMM) is a novel smart material based on magnetostrictive effect, and it is well suited to power ultrasonic transducer. Based on electromagnetic theory and vibration theory, the design and working principle of the magnetostrictive power ultrasonic transducer has been explained. This paper analyzed the dynamic characteristics of giant magnetostrictive materials under the outside magnetic field and deduced the wave equation of Terfenol-D rod, and the steady-state solution to the equation was obtained under given excitation. The speed and acceleration expressions of Terfenol-D were deduced by differentiating with respect to displacement equation. Based on developing mathematical models, computer imitation was made, and the result of modulation was analyzed from external conditions of transducer and inner structure of magnetostrictive material.

• Periodical: Applied Mechanics and Materials (Volumes 105-107)
• Pages: 1693-1696
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.105-107.1693
• Online since: September 2011
• Authors: Geng Xin Zeng, Biao Cao, Hai Quan Zeng
• Keywords: Dynamic Characteristic, Magnetostrictive, Terfenol-D, Ultrasonic Transducer

References

[1] B. Koc, S. Cagatay and K. Uchino: IEEE Transactions on Ultrasonics, Ferroelectrics, and Frenquency Control, Vol. 49 (2002), No. 4, p.495.

[2] E. Riera, Y. Golás and A. Blanco: Ultrasonics Sonochemistry, Vol. 11 (2004), No. 3, p.241.

[3] G.N. Weisensel, T.T. Hansen and W.D. Hrbek: Proceeding of SPIE, Vol. 3326 (1998), p.450.

[4] Z.F. Tang: Fundamental Theory and Experiments Study of Giant Magnetostrictive Actuator (Ph.D., zhejiang University, China 2005). ( In Chinese).

[5] J.C. Slaughter, M.J. Dapino and R.C. Smith: Proceedings of SPIE, Vol. 3985 (2000), p.366.

[6] M.J. Dapino, R.C. Smith and A.B. Flatau: IEEE Transactions on Magnetics, Vol. 36 (2000) No. 3, p.545.

[7] F. Stillesjo, G. Engdahl and Z.G. Wei: Proceedings of SPIE, Vol. 3992 (2000), p.594.

[8] W.J. Liu, L.S. Zhou and T.J. Xia: Acoustics and Electronic Engineering, (2005) No. 4, p.28. ( In Chinese).

[9] The members compiling Ferromagnetics in Department of Physics of Beijing University: Ferromagnetics (Science Press, China 1976). ( In Chinese).

[10] C.S. Zhao: Ultrasonic motors technologies and applications (Science Press, China 2007). ( In Chinese).
