The Design of Dynamic Vibration Absorber on the Engine of Fire Smoke Exhausting Robot

Abstract:

The vibration of fire smoke exhausting robot affects a lot on running quality. The rotational speed of engine is fixed and the vibration of the robot’s engine has a certain dominant frequency, so a dynamic vibration absorber is possible to reduce the vibration. In this paper a typical structure has been designed, and the linear relationship between dominant frequency and engine speed has been surveyed. The elongation of the spring has been deduced to the only key parameter due to the linear relationship and determined speed. An evaluation standard of damping effect was set up, the maximum acceleration value and root mean square value of acceleration and relative value of acceleration were taken as the evaluation indexes. Comparison tests were made, the damping effect was taken into account. The experimental results demonstrate the practicability and effectiveness of the new simplified absorber.

• Periodical: Applied Mechanics and Materials (Volumes 105-107)
• Pages: 180-184
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.105-107.180
• Online since: September 2011
• Authors: Shu Fang, Sheng Peng Liu, Jing Liang
• Keywords: Damping Effect, Dynamic Vibration Absorber, Fire Smoke Exhausting Robot

References

[1] Balakumar Balachandran, Edward B. Magrab, A.P. Balachandran. Vibrations. Nelson Engineering,2002,in press.

[2] David Edward Newland. Mechanical Vibration Analysis and Computation. DOVER PUBN INC.2006,in press.

[3] Yang Wen-xian, Jiang Jie-sheng. Study on the singular entropy of mechanical Canal [J]. Chinese Journal of Mechanical Engineering,2000,36(12):9-13.

[4] Information on http://forum.simwe.com/archiver/tid-451394.html.

[5] Hongkun Li, Peilin Zhou, Xiaojiang Ma. Pattern recognition of wearing of diesel engine piston and cylinder liner by using a novel methodology-hilbert spectrum entropy [J]. Proceedings of the Institute of Marine Engineering, Science and Technology.2005,A6t 43-48.

DOI: 10.1080/20464177.2005.11020301

[6] Information on http://www.docin.com/p-177118118.html.

[7] Boashash Boualem, Suclc Victor. Resolution measure criteria for the objective assessment of the performance of quadratic time frequency distributions[J]. IEEE Transactions on Signal Processing, 2003, 51:253-1 263.

DOI: 10.1109/tsp.2003.810300

[8] Yimin Zhang. Mechanical vibration.Beijing, Qinghua University Press,2007,in press.

[9] Genta G. An approximated approach to the study of motor vehicle with non-line shock absorbers. Messianic,1989,24(2):47-57.

DOI: 10.1007/bf01576003

[10] Wallasheck J. Dynamics of non-line shock absorbers. Int J Non-Linear Mech,1990,25(3): 99-308.
