On the Basis of Fuzzy and PID Double Control of Honing Machine Reciprocating Motion

Abstract:

As the improvement of honing velocity, acceleration and accuracy, corresponding requirements about control technology are put forward to meet the improvement of high machining efficiency. While the honing machine spindle reciprocating reversing control is the key control link, directly affects the ability of the machine abilities and quality. Aim at the traditional honing machine reciprocating motion cannot satisfy the requirement of high speed, high acceleration and high reversing accuracy. According to the characteristics of honing machine mechanism of reciprocating movement, establish its mathematic model and the system of fuzzy and PID double control model, and then the control system was conducted by using the tool of Simulink. The simulation result showed that using fuzzy and PID double control can make overshoots reduced compared with conventional single fuzzy control and PID control, and can well satisfied the system performance index.

• Periodical: Applied Mechanics and Materials (Volumes 105-107)
• Pages: 423-428
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.105-107.423
• Online since: September 2011
• Authors: Jia Li Zhao, Shan Shan Chen, Chi Bing Hu, Jun Gong
• Keywords: Fuzzy Double Control, Honing, PID Double Control, Reciprocating Motion

References

[1] J.M. WU: Key Technical Researches on Numerical Control Honing Machine (MS., Lanzhou University of Technology, China 2005), p.3. (In Chinese).

[2] Information on http: /skzx. miit. gov. cn.

[3] Y.D. ZHANG: Modern Honing Technology (Science Press, China 2007). (In Chinese).

[4] X. H Yi: Electrical Automation, Vol. 33 (2011) No. 1, p.36(In Chinese).

[5] R.J. ZHOU, L.N. ZHANG: Design on Fuzzy Neural Network Based on MATLAB and Fuzzytech ( Electronic industry press, China 2010). (In Chinese).

[6] G.Y. LI, Journal of System Simulation, Vol. 15 (2003) No. 10, p.1492(In Chinese).

[7] Z.H. MA, C.B. HU, J.M. WU: Journal of Lanzhou University of Technology, Vol. 32(2006) No. 5, p.59(In Chinese).

[8] D.X. FANG, Y.Q. YU, W. CHEN: Chinese Journal of Mechanical Engineering, Vol. 44(2008) No. 1, p.144(In Chinese).

[9] R. LIU, H.C. PAN, Y. CHEN, H.F. GONG: Chinese Journal of Mechanical Engineering, Vol. 20(2007) No. 3, p.350(In Chinese).

[10] F.B. LAI: Research on High-speed Numerical Control Honing Machine Control System (MS., Lanzhou University of Technology, China 2005), p.27. (In Chinese).
