Shaping Parameter Control of High-Speed Cold Roll-Beating Based on Simulation and Regression Analysis

Abstract:

High-speed cold roll-beating is a near-net shaping technology in which with the characteristic of metal plastic forming used, revolving roller with high speed is applied to roll and beat the blank shaft, then force mental to flow and form a component profile. In the forming process, matching between the process parameters and the part profile is key to implement and apply the technology. In this paper, the FEM model of the lead screw cold roll-beating forming is built, the ABAQUS software is used to simulate the forming process. Based on the simulation results, the orthogonal test is designed, influence of process parameters on groove depth and bulging height of cold roll-beating process are studied; multivariate regression models of maximum bulging height and groove depth relative to the process parameters are established, and the effectiveness of the models are verified, which is of important guiding significances for forming accurate profile of lead screw by controlling process parameters.

• Periodical: Applied Mechanics and Materials (Volume 109)
• Pages: 517-522
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.109.517
• Online since: October 2011
• Authors: Ming Shun Yang, Yan Li, Qi Long Yuan, Jian Ming Zheng
• Keywords: Cold Roll-Beating, Finite Element Method (FEM), Lead Screw, Regression Analysis, Shaping Parameter Control

References

[1] J. Jeswiet, M. Geiger U. Engel. Metal forming progress since 2000. CIRP Journal of Manufacturing Science and Technology. 1 (2008) 2-17.

DOI: 10.1016/j.cirpj.2008.06.005

[2] H. Krapfenbauer. New aspects for the mass production of spur gears by cold rolling. IPE International Industrial & Production Engineering. 8 (1984) 39-41.

[3] F. K. Cui, Yan. Li, Y. W. Zhou. Technologic Research on Rolling Involute Spline Axis. Transactions of the Chinese Society for Agricultural Machinery. 37 (2006) 189-192.

[4] F. K. Cui, X. J. He, C. M. Li, Y. Li. Shaping Movement Analysis and Simulation of Ballscrew Manufactured by Cold Rolling. Advanced Materials Research. 97-101 (2010) 4032-4035.

DOI: 10.4028/www.scientific.net/amr.97-101.4032

[5] Yan. Li, M. S. Yang, B. Li, Q. L. Yuan. Dynamics Simulation and Analysis of Lead Screw Cold Roll-Beating . Journal of Xi'an University of Technology. 25 (2009) 383-386.

[6] Y. Li , L. Zhang, M. S. Yang, Q.L. Yuan. Analysis of Lead Screw High-Speed Roll-beating Forming, Key Engineering Materials. 455 (2011) 151-155.

DOI: 10.4028/www.scientific.net/kem.455.151
