Inverse Kinematics with 3-Dimensational Tool Compensation for 5-Axis Machine Center of Tilting Rotary Table

Abstract:

The purpose of this paper is to develop a tool radius compensation method for a 5-axis horizontal machine center with a tilting rotary table. The generalized expression is presented first to determine the cutting contact location for any type of milling tools. The spindle orientation solved from a closed form of the inverse kinematics is applied for generating the postprocessor, and a compensating procedure is implemented to verify the offset path.

• Periodical: Applied Mechanics and Materials (Volumes 110-116)
• Pages: 3525-3533
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.110-116.3525
• Online since: October 2011
• Authors: Chieh Tung, Pei Lum Tso
• Keywords: 3D Compensation, 5-Axis Machining, Cutter Orientation, NC Program, Postprocessor, Tilting Rotary Table, Tool Parameters
