Numerical Analysis of Single Phase Flow Pressure Drop in a Horizontal Rifled Tube

Abstract:

Numerical analysis by using Fluent® has been carried out to investigate the pressure drop of single phase flow in a 2 meter long of rifled tube and smooth tube which is placed horizontally. The rifled tube or also known as spiral internally ribbed tube that is used in this investigation has an outside diameter 45.0 mm and inside equivalent diameter1 of 33.1 mm while the smooth tube has an outside diameter 45.0 mm and inside diameter 34.1 mm. The working fluid that is used in this investigation is water. In this numerical analysis, realizable k-epsilon model has been chosen to solve the fully developed turbulence flow in both the tubes. The result of the pressure drop which is obtained from simulation shows that the pressure drop in rifled tube is about 1.69-1.77 times much higher than pressure drop in smooth tube. The high pressure drop in rifled tube comparing to smooth tube is due to the helical rib in the rifled tube which causes swirling effect near the wall. A correlation has been proposed for the single phase friction factor of the rifled tube.

• Periodical: Applied Mechanics and Materials (Volumes 110-116)
• Pages: 4398-4405
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.110-116.4398
• Online since: October 2011
• Authors: Soo Poey Lam, Abdul Wahab Abas, Saparudin Ariffin, Woon Kiow Lee
• Keywords: Computational Fluid Dynamics (CFD), Pressure Drop, Rifled Tube, Single Phase Flow

References

[1] Manglik, R. M. (2003). Heat transfer enhancement,. In: Bejan, A. and Kraus, A. D. (Eds. ). Heat transfer handbook. New Jersey: John Wiley & Sons pp.1029-1130.

[2] Cheng, L. X. and Chen, T. K. (2006). Study of single phase flow heat transfer and friction pressure drop in a spiral internally ribbed tube. Chemical Engineering Technology, Vol. 29, No. 5, pp.588-595.

DOI: 10.1002/ceat.200600014

[3] Köhler, W. and Kastner, W. (1980). Heat transfer and pressure loss in rifled tube. Proceeding of 8th International Teat Transfer Conference, Vol. 5, pp.2861-2865.

DOI: 10.1615/ihtc8.1380

[4] Cheng, L. X. and Chen, T. K. (2007). Study of vapor liquid two-phase frictional pressure drop in a vertical heated spirally internally ribbed tube. Chemical Engineering Science, Vol. 62, No. 3, pp.783-792.

DOI: 10.1016/j.ces.2006.10.016

[5] Tucakovic, D. R. et al. (2007). Thermal- hydraulic analysis of a steam boiler with rifled evaporating tubes. Applied Thermal Engineering, Vol. 27, No. 2-3, pp.509-519.

DOI: 10.1016/j.applthermaleng.2006.06.009

[6] Kim, C. H. et al. (2005) Critical heat flux performance for flow boiling of R-134a in vertical uniformly heated smooth tube and rifled tubes. International Journal of Heat and Mass Transfer, Vol. 48, No. 14, pp.2868-2877.

DOI: 10.1016/j.ijheatmasstransfer.2005.01.039

[7] Çengel, Y. A. (2003). Heat transfer a practical approach. Boston: McGraw Hill. 2nd Edition.

[8] Gambit 2. 4 electronic documentation.

[9] Fluent 6. 3 electronic documentation.

[10] Kundu, P. K. and Cohen, I. M. (2004) Fluid Mechanics. California: Elsevier Academic Press.
