Effect of Microstructure on CTOD of Welded Joints for Offshore High-Strength Steel

Abstract:

Based on the CTOD test, metallographic test is done. The effect of microstructure on CTOD of welded joints for offshore high-strength steel has been analyzed by SEM. The microstructure of different samples in a welding procedure and two different welding procedures are compared. From the microscopic point of view, the reasons why the toughness of the second group welded joints is better than the first group’s and why the toughness of the same group welded joints is different have been determined. And the main microstructure found in EQ70 steel welded joints is the ferrite, tempered sorbite and a small amount of pearlite. Besides some carbide particles are on the matrix of tempered sorbite. The material toughness with a small amount of acicular ferrite is better. Inclusions and pores also seriously affect the toughness of welded joints. Reducing the welding heat input appropriately can refine the grain of CGHAZ and improve toughness. But hardened microstructure may occur owing to too low welding heat input.

• Periodical: Applied Mechanics and Materials (Volumes 117-119)
• Pages: 1905-1911
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.117-119.1905
• Online since: October 2011
• Authors: Li Na Niu, Zhang Mu Miao, Tao Ma, Gang Chen
• Keywords: Crack Tip Opening Displacement (CTOD), Inclusion, Microstructure, Toughness, Welded Joint

References

[1] Boli Chen. Analysis on Countermeasures and shortcomings of the Welding Engineering.Beijing: Machinery Industry Press (2006)(In Chinese).

[2] Zhangmu Miao, Zhenyu Wang. Wide and Heay Plate. Vol. 28 (2004), p.6.

[3] British Standard Institution.BS7448:Part2:Method for Determination of KIC, Critical CTOD and Critical J Values of Welds in Metallic Materials. London: British Standard Institution, 1997.

DOI: 10.3403/01124251

[4] Offshore Standard DNV-OS-C401-2008: Fabrication and Testing of Offshore Structures.

[5] Yanping Zhu,Songnian Lou,Yimin Tang.Materials for Mechanical Engineering.Vol. 17 (1993), p.2.

[6] Enda Keehan. Effect of Microstructure on Mechanical Properties of High Strength Steel Weld Metals. Ph.D dissertation. Dept. of Physics, Chalmers University of Technology and Göteborg University. Göteborg, Sweden, 2004.
