Study on the Force of Flexible Vacuum Cup Fixture for Aircraft Skin Trimming

Abstract:

When the aircraft skin is in the process of trimming and on the flexible vacuum cup fixture, by analyzing the stress to the aircraft skin and studying the relationship between vacuum pressure and deformation of aircraft skin, vacuum pressure, vacuum force and cutting parameters, the relationship which between vacuum pressure of flexible fixture and cutting parameters, clamping points of flexible fixture, friction coefficient of cup and aircraft skin, the maximum deformation allowed on aircraft skin is obtained. It provides a methodology to improve the precision of trimming of aircraft skin components.

• Periodical: Applied Mechanics and Materials (Volumes 117-119)
• Pages: 545-549
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.117-119.545
• Online since: October 2011
• Authors: Ai Li Zou, Liang Wang, Dong Sheng Li
• Keywords: Cutting Force, Flexible Fixture, Vacuum Cup, Vacuum Pressure

References

[1] Kline W A,de Vor R E,Shareef I A. The prediction of surface accuracy in end milling[J].Transactions of the ASME Journal of Engineering for Industry,1982,104:272-278.

DOI: 10.1115/1.3185830

[2] Kang Yonggang,Wang Zhongqi, Jiang Chengyu. An Efficient Algorithm for Calculations of Surface Errors in Peripheral Milling[J] .ACTA AERONAUTICA ET ASTRONAUTICA SINICA. 2007,28(5):1262-1267. in Chinese

[3] Sutherland J W,de Vor R E.An improved method for cutting force and surface error prediction in flexible end milling systems[J].Transactions of the ASME Journal of Engineering for Industry,1986,108:269-279.

DOI: 10.1115/1.3187077

[4] Li Mu, Chen Weifang. Study of Simulation and Prediction Approach of Milling Deformation of Workpieces[J].MACHINERY,2010.48(1):51-54.

[5] Tsai J S,Liao C L. Finite-element modeling of static surface errors in the peripheral milling of thin-walled workpieces[J].Journal of Materials Processing Technology,1999,94:235-246.

DOI: 10.1016/s0924-0136(99)00109-0

[6] Budak E, Altintas Y. Modeling and avoidance of static fo-rm errors in peripheral milling of plates[J].International Journal of Machine Tools and Manufacturing,1995,35(3):459-476.

DOI: 10.1016/0890-6955(94)p2628-s

[7] Budak E, Altintas Y. Peripheral milling conditions for improved dimensional accuracy[J]. International Journal of Machine Tools and Manufacturing,1994,34(3):907-918.

DOI: 10.1016/0890-6955(94)90024-8

[8] Wan Min, Zhang Weihong. Investigation on Cutting Force Modeling and Numerical Prediction of Surface Errors in Peripheral Milling of Thin-walled Workpiece[J]. ACTA AERONAUTICA ET ASTRONAUTICA SINICA.2005,26(5):598-603. in Chinese
