The Double-Station Fixture Based on Air-Liquid and Air-Liquid-Mechanical Composite Transmission Technology and its Application in Press

Abstract:

When adopting the air-liquid and air-liquid-mechanical composite transmission technology, the comparative advantages of various transmission techniques can be played, while their shortcomings can be avoided. The efficient fixture and press with double-station based on these composite transmission technology are introduced, and their working principles and mechanical formulas are given out. The innovative design of the fixture and press with double station can achieve the two station order-processing operations when only using one drive cylinder, which have high efficiency, the large output force, and will not pollute the environment.

• Periodical: Applied Mechanics and Materials (Volumes 121-126)
• Pages: 1372-1376
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.121-126.1372
• Online since: October 2011
• Authors: Kang Min Zhong, Ying Hua Xiao, Ming Di Wang
• Keywords: Air-Liquid Booster, Fixture, Press, Toggle Force Amplifier

References

[1] Li Ru.Machine Design,2006,23(12):56-58

[2] Feng,Jinyun,Gu Jinghua,Shi Xudong.Modular Machine tool and automatic manufacturing technology,2008(12):81-82,85

[3] Shen Zaifu,Jia Junpeng,Zhong Kangmin.Machine manufacturing,2010(3)：60-61

[4] Lu Lin,Zhong Kangmin. Machine Design and research,2010(5):47-49

[5] Dou Yunxia,Zhong Kangmin. Maunfacturing Technolo gy and Machine Tool,2010(11)：58-59

[6] Wang Jin-e, Dou Yun-xia, Zhong Kang-min. Journal of Engineering Design(CHINA),2009,16(4)：242-246

[7] Wang, Jin E.; Cui, Zhi Lei; Zhong, Kang Min. Advanced Materials Research, v 201-203, pp.1464-1468, (2011)

[8] Zhong Kangmin, Dou Yunxia, Su Dongning, Wang Hongyan. Proceedings of ASME2009 International Mechanical Engineering Congress and Exposition.

[9] Si Guangju, Zhong Kangmin. 2009 IEEE International Conference on Mechatronics and Automation, ICMA 2009, pp.1596-1600, 2009.a a a
