Optimization of Ultrasonic Plastic Welding Horns on Amplitude Uniformity

Abstract:

This research integrated finite element analysis (FEA) and optimum design to obtain a fast, accurate and automatic optimization system for the design of an ultrasonic horn. The optimization system was developed to achieve uniform amplitude distribution on the output surface of a block shaped horn for the ultrasonic plastic welding. Agreement between the experimental and numerical data proved that this optimization system was efficient in the design of ultrasonic horns.

• Periodical: Applied Mechanics and Materials (Volumes 121-126)
• Pages: 278-282
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.121-126.278
• Online since: October 2011
• Authors: Jung Chung Hung, Yen Pin Tsai, Ching Hua Hung
• Keywords: Amplitude Uniformity, Finite Element Analysis (FEA), Optimum Design, Ultrasonic Horn

References

[1] K. H. W. Seah, Y. S. Wong, and L. C. Lee: J. Mater. Process. Technol. Vol. 37 (1993), pp.801-816.

[2] S. G. Amin, M. H. M. Ahmed, and H. A. Youssef: J. Mater. Process. Technol. Vol. 55 (1995), pp.254-260.

[3] A. Cardoni and M. Lucas: Ultrasonics Vol. 40 (2002), pp.365-369.

[4] K. Adachi and S. Ueha, J. Acoust: Soc. Am. Vol. 87 (1990), pp.208-214.

[5] N. Metropolis, A. W. Rosenbluth, M.N. Rosenbluth, A.H. Teller, and E. Teller: J. Chem. Phys. Vol. 21 (1953), pp.1087-1092.

DOI: 10.1063/1.1699114

[6] S. Kirkpatrick, C. D. Gelatt, and M. P. Vecchi: Science, Vol. 220 (1983), pp.671-680.
