Simulation on Temperature Field of Gap Oil Film in Constant Flow Hydrostatic Center Frame

Abstract:

In order to solve the thermal deformation of the hydrostatic center frame in the heavy type horizontal lathe, a simulation research concerning temperature field of hydrostatic center frame is described. The Finite Volume Method of CFX has been used to compute three-dimensional temperature field of gap fluid between workpiece and bearing pillow. This research theoretically analyzes the influence of angular velocity on the bearing temperature performance according to lubricating theory and computational fluid dynamics, and it has revealed its temperature distribution law of gap oil film. Results indicate that an improved characteristic will be affected by angular velocity easily, and oil cavity temperature increases by gradually with angular velocity enhancing. Through this method, the safety of a hydrostatic center frame can be forecasted, and the optimal design of such products can be achieved, so it can provide reasonable data for design, lubrication, experience and thermal deformation computation for hydrostatic center frame in the heavy type horizontal lathe.

• Periodical: Applied Mechanics and Materials (Volumes 121-126)
• Pages: 4706-4710
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.121-126.4706
• Online since: October 2011
• Authors: Yong Hai Li, Xiu Li Meng, Xiao Dong Yu, Bo Wu, Chun Li Gao, Zhi Xin Qiu, Yan Qin Zhang, Hui Jiang, Zhi Min Shi
• Keywords: Constant Flow (CF), Hydrostatic Center Frame, Simulation Research, Temperature Field

References

[1] Zhi Gangsuo:  Heavy Machinery, Vol. 2 (2003), pp.11-14.

[2] Zhang guoyuan: Lubrication Engineering, Vol. 80, (2006), pp.4-7.

[3] Wang Ruichang:  Heavy Machinery, Vol. 6 (2002), pp.38-41.

[4] Fu Yanli: Mechanical Science and Technology, Vol. 21 (2002), pp.711-714.

[5] T.A. Osman, Z.S. Safar and M.O.A. Mokhtar: Tribology International Vol. 24(1991), pp.137-141.

[6] T. Jayachandra Prabhu and N. Ganesan: Wear Vol. 93(1984), pp.219-231.

[7] T. Jayachandra Prabhu and N. Ganesan: Wear Vol. 92(1983), pp.269-277.

[8] Van Beek A, Van Ostayen RAJ: Tribology International, Vol. 30, (1997), pp.33-39.

[9] Pang Zhi Cheng: Liquid Gas Hydrostatic Technology (Heilongjiang the people press, Harbin 1981).

[10] Chen Bo Xian: Fluid Theory of Lubrication and Their Application (Mechanical industry press, Beijing 1991).

[11] Han Zhan, Wang Jing, Lan Xiao Ping: The FLUENT Fluid Project Simulates Calculating an Example and Applies(Press of Beijing Institute of Technology, Beijing 2004).

[12] Wang Fu Jun: Calculation Flow Mechanics Analyses FLUENT Software Principle and Applies (Tsing Hua University press, Beijing 2004).
