Solving Intrinsic Parameters of Camera Calibrated from Controlled Motion Sequences and Homography

Abstract:

A camera calibration based on controlled motion sequences and homography is adopted. First condition of unique solution for constrained equation set is proofed. Then two sets three orthogonal motions are carried out for camera in manipulator, thus 6 homographic matrixes of plane are obtained at 7 view points, and thus the intrinsic parameters of camera are achieved. The experiments on real images validate our technology based on homography.

• Periodical: Applied Mechanics and Materials (Volumes 121-126)
• Pages: 4716-4720
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.121-126.4716
• Online since: October 2011
• Authors: Dong Yuan Ge, Xi Fan Yao, Wen Jiang Xiang, Yuan Liu
• Keywords: Homography, Intrinsic Parameter, Orthogonal Translational Motion, Self-Calibration

References

[1] Lisa Dron. Dynamic camera self-calibration of from controlled motion sequences. In: Proc. CVPR'93, 1993, pp.501-506.

[2] Fenglei Du, M ichael Brady. Self-calibration of the intrinsic parameters of cameras for active vision systems. In: Proc. CVRP'93, 1993, pp.477-482.

[3] Luong Q T, Faugeras O D. Self-calibration of a moving camera from point correspondences and fundamental matrices[J]. Inter. J. of Camputer Vision, vol. 27, March, 1997, pp.261-289.

[4] Peter Sturm. Self-calibration of a moving zoom-lens camera by pre-calibration [J]. Image and Vision Computing, vol. 15, 1997, pp.583-589.

DOI: 10.1016/s0262-8856(97)00015-2

[5] LEI Cheng, WU Fu-Chao, HU Zhan-Yi. A new camera self-calibration method based on active vision system. Chinese J. Computers. Vol. 23, November, 200, pp.1130-1139.

[6] Wu Fu-Chao, ZHANG Bei-Bei. Homography between two translation view points. Journal of Anhui University Nature Science Edition. Vol. 24, September 2000, pp.40-45.

[7] Ma S D. A self-calibration technique for active vision systems [J]. IEEE Trans. Robotics and Autom. Vol. 12, Jan, 1996, pp.114-120.

[8] Bill Triggs. Autocalibration and the absolute quadric [C]. IN: Proc CV PR' 97, 1997, pp.609-614.

[9] WU Fu-Chao, LI Hua and HU Zhan-yi. New Active Vision based Camera Self-calibration Technology [J]. Acta Automatica Sinica. Vol. 27, Novrmber, 2001, pp.752-762.

[10] SUN Feng-mei, HU Zhan-yi. Some Properties about the Constraints on the Camera's Intrinsic Parameters from Homography [J]. Journal of Computer-aided Design & Computer Graphics. Vol. 19, May, 2007, pp.647-650.

[11] López-Nicolás G., Gans N.R., Bhattacharya S., et al. Homography-Based Control Scheme for Mobile Robots With Nonholonomic and Field-of-View Constraints [J]. IEEE Trans. on systems, Man, and Cybernetics, Part B: Cybernetics. Vol. 40, (4): 2010, pp.1115-1127.

DOI: 10.1109/tsmcb.2009.2034977
