Finite Element Analysis and Optimization Research of Mounting Bracket of a Mini Van

Abstract:

Powertrain mounting bracket is a vital part in the car, its strength is more important for the vehicle lifetime, and lightweight is becoming the aim of structure design. According to the optimization design idea, a common formula of size optimization was deduced. And the structure of the mounting bracket was analyzed by using Optistruct software and the bracket in real work condition was studied. In the premise of meeting the stress, the optimal design of the bracket was finished. And the result show that the optimal design is right and reasonable, the quality of optimized bracket was reduced 37.28%, and achieved good results.

• Periodical: Applied Mechanics and Materials (Volumes 121-126)
• Pages: 4811-4815
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.121-126.4811
• Online since: October 2011
• Authors: Shu Hua Liao, Chuan Sheng Cheng
• Keywords: HyperMesh, Optimal Design, Powertrain Mounting Bracket, Strength Analysis

References

[1] Jingmin Sun, Yingchun Liang. Mechanical optimal design [M]. Machinery Industry Press. 2009. 8, in China.

[2] Bing Zhong. Optimal Design of Mine frame basedonHypermesh [J]. MineMachinery. 2010. 6 (31), 26-27, in China.

[3] Zhongming Hou, etc. Free size optimization of Telescopic based on Hyperworks [J]. China construction machinery. 2009. 12 (40), 37-41, in China.

[4] Zhaoping Lv. Research on optimizing design of the Engine Mount System of a big Mini Van[D]. Master degree paper, 2010, 4, in China.

[5] Nan Kyu Lee, etc. Design of engine mount using finite element method and optimization technique. SAE paper 980379.
