Research on Mathematic Model and Measuring Method of Moving Beam Attitude in Large Forging Hydraulic Press

Abstract:

The moving beam of large forging hydraulic press is taken as a research object. A mathematic model of moving beam’s six freedom degrees attitude is established. According to the mechanical feature and special working conditions of large forging hydraulic press, a non-contacted method for moving beam attitude measuring which based on machine vision is proposed. The basic principle and composition of the system are introduced. The system is applied in 300MN large forging hydraulic press, and large amounts of monitoring data are collected which confirm that the measuring method is effective. The research result is helpful for the safety operation and maintenance of large forging hydraulic press.

• Periodical: Applied Mechanics and Materials (Volumes 128-129)
• Pages: 1213-1216
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.128-129.1213
• Online since: October 2011
• Authors: Hui Chen, Jian Ping Tan, Jin Li Gong, Xian Yue Cao, Ji Neng Zhou
• Keywords: Attitude Measuring, Hydraulic Press, Machine Vision, Moving Beam

References

[1] YU Xin-lu. in: Modern Design Theory on Hydraulic Press[M]. Beijin: China Machine Press, (1987).

[2] YU Xin-lu. in: Hydraulic Press[M]. Beijing: China Machine Press, (1990).

[3] Liang Mi. in: Research of Deformation of 300MN Hydraulic Press Activity Beam[J], submitted to Machine Design & Research. 2010 (26). 1. P 108-111.

[4] Zhou Junfeng, Tan Jianping. in: The Design of Synchronism Measuring System for Moving beam of 300MN Die Forging Press[J], submitted to Machinery & Electronics. 2004(8). P51-53.

[5] Qing K.E. in: Method of Recognizing of Chip Shape Based on Machine Vision Technology[J], submitted toAdvanced Materials Research, 2011 V188, pp.158-161.

[6] Chen F.N. in: Detect Black Germ in Wheat Using Machine Vision, Proceedings-International Conference on Computer Distributed Control and Intelligent Environmental Monitoring CDCIEM 2011, pp.36-39.

DOI: 10.1109/cdciem.2011.566

[7] Jog, Gauri M. in: Testing in Harsh Conditions: Tracking Resources on Construction Sites With Machine Vision[J] , submitted to Automation in Construction, 2011, V20, pp.328-337.

DOI: 10.1016/j.autcon.2010.11.003

[8] Hui Chen, Jianping Tan, Yufeng Peng, and Lingyun Quan. In: A Digital and Non-contact Method for Detecting Moving Beam Eccentricity in Forging Hydraulic Press Based on Machine Vision [J]. 2010 International Conference on Measuring Technology and Mechatronics Automation, 2010, 1 : 64～67.

DOI: 10.1109/icmtma.2010.751
