Experiment Study and Design of Measurement System of the Total Electrical Field on the Ground Level under HVDC Transmission Lines

Abstract:

Based on the technology of virtual instrument, a set of measurement system of the total electric field on the ground level under HVDC transmission lines is developed. After the hardware and software system are built up, some tests are made in laboratory to show the validity of the system. Finally, experiment results are given and analyzed. The developed measurement system can be used to measure the total electric field on the ground level under HVDC transmission lines, and can provide support for the evaluation of the electromagnetic environment of the HVDC transmission lines.

• Periodical: Applied Mechanics and Materials (Volumes 128-129)
• Pages: 1452-1455
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.128-129.1452
• Online since: October 2011
• Authors: Xin Rui Zhao, Tie Bing Lu, Yu Hong Dong
• Keywords: HVDC, Probe, Signal Processing, Total Electric Field, Virtual Instrument (VI)

References

[1] P. Sarma Maruvada, in: Corona performance of high-voltage transmission lines [M]. Hertfordshire, Research studies press, (2000).

[2] Long weihua and Gu yonggang, in: LabvIEW 8. 2. 1 DAQ data and acquisition [M]. Beijing, Tsinghua Press, (2008).

[3] P. Sarma Maruvada R.D. Dallaire and R. Pedneault, in: Development of field-mill instruments for ground-level and above-ground electric field measurement under HVDC transmission lines[J]，IEEE Transactions on Power Apparatus and Systems, 1983, 102(3): 738- 744.

DOI: 10.1109/tpas.1983.318035

[4] Zhao wanjun, in: HVDC transmission engineering technology [M]. Beijing, China Power Press，(2004).

[5] DL/T 1089—2008, The measuring method of total electric field and density of ionic current of DC convertor station and lines. Beijing, China Power Press, (2008).
