Research on the Suppression of Input Power Disturbance for Single-Phase Photovoltaic Grid-Connected Inverter

Abstract:

The output power of single-phase PV inverter is AC and the input power is DC，so there exists fluctuations in the power transmission. Generally, the fluctuations can be removed by using coupling capacitors. However, the voltage fluctuations of coupling capacitors will result in corresponding input power fluctuations, and will affect the maximum power tracking of the system. In this paper, the power transfer process is analysised, and a theoretical derivation to voltage fluctuations of the generatrix capacitor and the impact on the input currents is designed.The corresponding correction control algorithm of subdivision control is developed according to its characteristics. The feasibility of the solution is verified by the 3KW experimental prototype.

• Periodical: Applied Mechanics and Materials (Volumes 128-129)
• Pages: 243-246
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.128-129.243
• Online since: October 2011
• Authors: Kai Chen, Shu Lin Tian, Yu Hua Cheng
• Keywords: Current Ripple, Maximum Power Point Tracking (MPPT), Power Swing, PV Inverter

References

[1] Lee ChunYao, Chen Pohung, in: Maximum power point tracking (MPPT) system of small wind power generator using RBFNN approach. Expert Systems with Applications, v 38, n 10, pp.12058-12065, September 15, (2011).

DOI: 10.1016/j.eswa.2011.02.054

[2] Kakosimos Panagioris, Kladas Antonios G, in: Implementation of photovoltaic array MPPT through fixed step predictive control technique. Renewable Energy, v 36, n 9, pp.2508-2514, September (2011).

DOI: 10.1016/j.renene.2011.02.021

[3] M. Ciobotaru, T. Kerekes, R. Teodorescu, and A. Bouscayrol, in: PV Inverter Simulation using Matlab/Simulink Graphical Environment and PLECS Blockset, IEEE Industrial Electronics, IECON 2006, 32nd Annual Conference on Volume , Issue , Nov. 2006, p.5313.

DOI: 10.1109/iecon.2006.347663

[4] S.B. Kjaer, J. K. Pedersen and F. Blaabjerg, in: A review of single-phase grid-connected inverters for photovoltaic modules, IEEE Transactions on Industry Applications, Vol. 41, No. 5, pp.1292-1306, (2005).

DOI: 10.1109/tia.2005.853371

[5] N. Kasa, T. Iida and Liang Chen, in: Flyback Inverter Controlled by Sensorless Current MPPT for Photovoltaic Power System, IEEE Transactions on Industrial Electronics, Vol. 52, pp.1145-1152, (2005).

DOI: 10.1109/tie.2005.851602

[6] M. Karppanen., T. Suntio., M. Sippola, in: Dynamical Characterization of Input-Voltage-Feed forward-Controlled Buck Converter, IEEE Trans. On Industrial Electronics Vol. 54, pp.1005-1013, (2007).

DOI: 10.1109/tie.2007.892732
