Polarization Multiplexing, Angle Multiplexing and Circumrotation Multiplexing Holographic Recording Experiments with 3-Indoly-Benzylfulgimide/PMMA Film

Abstract:

Fulgide is well-known as a thermally irreversible organic photochromic compound. The fulgide films can be applied as recording materials in ordinary holography and polarization holography, which were respectively based on the photochromic and photoinduced anisotropy properties. In this report, different kinds of multiplexing holographic storage, like angle multiplexing, circumrotation multiplexing and polarization multiplexing are realized in a 3-indoly-benzylfulgimide/ PMMA film for the first time, where 5 images, 18 images and 2 images are stored at the same position of the film, and diffracted without crosstalk with each other. It is proved that 3-indoly-benzylfulgimide film has spatial resolution of 6300lines/mm, sensitivity of 2.89 × 10^-3cm²/mJ at 632.8nm on the polarization direction of the exciting beam, fatigue resistance of 70 times, thermal stability of 14 months and has advantages like low cost, easy to used, rewritable, long life time at room temperature for both states, and high signal to noise ratio. Overall, 3-indoly-benzylfulgimide is a better rewritable holographic storage medium, but the fatigue resistance and thermal stability should be improved.

• Periodical: Applied Mechanics and Materials (Volumes 130-134)
• Pages: 2035-2041
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.130-134.2035
• Online since: October 2011
• Authors: Zheng Yue Zong, Neimule Menke, Bao Li Yao, Ying Li Wang, Yi Chen
• Keywords: Angle Multiplexing, Circumrotation Multiplexing, Fulgide, Holographic Storage, Polarization Multiplexing

References

[1] Y.H. Kang, K. Kim, B. Lee: Volume hologram scheme using optical fiber for spatial multiplexing. Opt. Lett. 22 (1997), p.739.

DOI: 10.1364/ol.22.000739

[2] F.H. Mok: Angle-multiplexed storage of 5000 holograms in lithium niobate. Opt. Lett. 18(1993) , p.915.

DOI: 10.1364/ol.18.000915

[3] K. Curtis, A. Pu, D. r Psaltis: Method for holographic storage using perist rophic multiplexing. Opt. Lett. 19(1994), p . 993.

DOI: 10.1364/ol.19.000993

[4] Y.H. Lee, S.D. Sohn: Optical implementation of orthogonal phase-code multiplexing. Opt. Lett. 26(2001), p. (1990).

DOI: 10.1364/ol.26.001990

[5] W.C. Su, C.C. Sun, N. Kukhtarev and A.E.T. Chiou: Polarization-multiplexed volume holograms in LiNbO3 with 90-deg geometry. Opt. Eng. 42(2003), p.9.

[6] S. Campbell, X. Yi, P. Yeh: Hybrid sparse-wavelength angle-multiplexed optical data storage system. Opt. Lett. 19 (1994) , p.2161.

DOI: 10.1364/ol.19.002161

[7] M. Huang, H. Yao, Z. Chen et al: Study on the character of novel green light sensitive high-density digital holographic photopolymer. Acta Physica S inica, 51(2002), p.2536 (in Chinese).

[8] W.D. Koek, N.B. hattacharya and J.J.M. Braat: Holographic simultaneous readout polarization multiplexing based on photoinduced anisotropy in bacteriorhodopsin. Opt. Lett. 29(2004), p.101.

DOI: 10.1364/ol.29.000101

[9] Y. Yokoyama: Fulgides for memories and switches. Chem. Rev. 100 (2000).

[10] Y. Chen, C. Wang, M. Fan, B. Yao and N. Menke: Photochromic fulgide for holographic recording. Opt. Mat. 26(2004).

DOI: 10.1016/j.optmat.2004.01.004

[11] R.A. Lessard, C. Lafond, G. Darderian, J.L. Gardette, A. Rivaton, M. Bolte: Fulgide-based WRE holographic materials: influence of the matrix on the fatigue process. Proc. SPIE, 5216(2003), p.139.

DOI: 10.1117/12.508323

[12] K.D. Belfield, Y. Liu, R.A. Negres, M. Fan, G. Pan, D.J. Hagan, and F.E. Hernandez: Two-Photon Photochromism of an Organic Material for Holographic Recording. Chem. Mater. 14(2002), p.3663.

DOI: 10.1021/cm0107981

[13] N. Menke, B. Yao, Y. Wang, Y. Zheng, M. Lei, L. Ren, G. Chen, Y. Chen, M. Fan, T. Li: Optical image processing using the photoinduced anisotropy of pyrrylfulgide. Journal of the Optical Society of America A, 23(2006), p.267.

DOI: 10.1364/josaa.23.000267

[14] Tao. S: Optical Holographic Storage (First Edition). Beijing University Press, Beijing, (1998)p.267.

[15] N. Menke, B. Yao, Y. Wang and Y. Chen: Polarization holography in 3-indoly- benzylfulgimide/PMMA film. Journal of Atomic, Molecular, and Optical Physics (International Journal), (2011) (accepted).

DOI: 10.1155/2011/509507

[16] J. Du, N. Menke, B. Yao, Y. Wang and Y. Chen: Photoreaction constants of fulgide films at different wavelengths, Proceedings of IEEE WMSE 2011, Nanjing, China, (2011) (accepted).

DOI: 10.1109/rsete.2011.5965760
