Modeling of Rope Longitudinal Vibration on Flexible Hoisting System with Time-Varying Length

Abstract:

Aimed at the longitudinal vibration of rope hoisting system with time-varying length, the governing equations are developed employing the Hamilton’s principle considering mutual influence of the rigid motion and deformation of rope. The Galerkin’s method is used to discretize the governing equations. In the mean time, The motions of elevator hoisting system were illustrated to evaluate the proposed mathematical models. The results of simulation show that the modeling methods can represent the longitudinal vibration of rope hoisting system with time-varying length in the paper. The governing equations derived can provide guidelines for further study on flexible hoisting system.

• Periodical: Applied Mechanics and Materials (Volumes 130-134)
• Pages: 2783-2788
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.130-134.2783
• Online since: October 2011
• Authors: Ji Hu Bao, Peng Zhang, Chang Ming Zhu
• Keywords: Elevator, Flexible Hoisting System, Longitudinal Vibration, Rope

References

[1] W.D. Zhu and Y. Chen. Forced response of translating media with variable length and tension: application to high-speed elevators. Institute of Mechanical Engineers Journal of Multi-body Dynamics, 2005, 219: 35-53.

DOI: 10.1243/146441905x10014

[2] S. Y. Lee and M. Lee. A new wave technique for free vibration of a string with time-varying length. Journal of Applied Mechanics, 2002, 69: 83-87.

DOI: 10.1115/1.1427337

[3] Terumichi Y., Ohtsuka M., YoshizawaM., Tsujioka Y. Nonstationary vibrations of a string with time-varying length and a mass-spring system attached at the lower end. Nonlinear Dynamics, 1997, 12: 39-55.

DOI: 10.1115/detc1993-0092

[4] W.D. Zhu and Ni J. Energetics and stability of translating media with an arbitrarily varying length. Journal of Vibration and Acoustics, 2000, 122(7): 295-304.

DOI: 10.1115/1.1303003

[5] R.M. Chi and H.T. Shu, Longitudinal vibration of a hoist rope coupled with the vertical of an elevator car. Journal of Vibration and Acoustics, 148(1): 154-159.

DOI: 10.1016/0022-460x(91)90826-6

[6] Young Man Cho, Rajesh Rajamani. Identification and experimental validation of a scalable elevator vertical dynamic model. Control Engineering Pratice, 2001, 9: 295-304.

DOI: 10.1016/s0967-0661(00)00112-x

[7] Zhang Peng, Zhu Chang, Zhang Liangjuan. Analyses of longitudinal vibration and energetic on flexible hoisting systems with arbitrarily varying length. Journal of Shanghai JiaoTong University, 2008, 42(3): 481-488.

[8] Lu Youfang. Flexible Multi-body dynamics. China Higher Education Press, 1996: 30-35.
