Research on Properties of PZT Piezoelectric Ceramics by Finite Element Softeware ADINA

Abstract:

In this paper, the finite element model of piezoelectric ceramics in line with the experiment results was established according to piezoelectric structure field and the coupling of the electric field, deformation of representative PZT piezoelectric ceramics under the voltage was analysed in using finite element analysis software ADINA according to establishing geometric model, defining boundary conditions and materials, Coupling calculation. Consistency between simulation results and experimental results is improved and lay the foundation for the realization of the piezoelectric ceramic shapes and vibration control.

• Periodical: Applied Mechanics and Materials (Volumes 130-134)
• Pages: 3233-3236
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.130-134.3233
• Online since: October 2011
• Authors: Chen Jie Guo, Chang Song Zhang
• Keywords: Coupling Effect, Finite Element Analysis (FEA), Piezoelectric Ceramic (PZT)

References

[1] GAUDENZI P, BATHE K J: Journal of Intelligent Materials Systems and Structures, 1995, 6(6): 266-273.

[2] CHANDRASHEKHARA K, BHATIA K: Smart Materials and Structures, 1993, 2(2): 31-39.

[3] PENG X Q, LAM K Y, LIU G R: Journal of Sound and Vibration, 1998, 209(4): 635-650.

[4] ANDERSON E H, CRAWLEY E F: Space Systems Laboratory SSL 5-89, Massachusetts Institute of Technology, Cambridge, MA 02139, (1989).

[5] GAUDENZI P, BATHE K J: Proceedings of the 4th International Conference on Adaptive Structures, Nov. 2-4, Köln, Germany, (1993).

[6] TZOU H S, TSENG C I: Journal of Sound and Vibration, 1990 138 (1): 17-34.

[7] Lin Qirong, Liu Zhengxing: Applied Mathematics and Mechanics, 2001, 22(9): 969-975.

[8] Ma Jun, Zhang Xiong: Engineering Mechanics. 2005, 22 (2): 57-62.
