Dynamic Model of Gears with Trapped Oil and Coupled Analysis in External Spur-Gear Pump

Abstract:

In order to understand the vibration characteristics of gears based on trapped-oil in external spur-gear pump, from the calculations of trapped-oil pressure and hydraulic load and contact stiffness and trapped-oil stiffness, etc., a dynamic model coupled with trapped-oil pressure was derived for the gears, then an iterative operation based on Runge-Kutta method was used for analyzing the model, therefore the data related to trapped-oil pressure and the vibration displacement and the vibration velocity were obtained in a periodic of trapped oil, and the impact of different backlash value and different distance between two unloading grooves on trapped oil pressure and dynamic characteristics of gears was briefly analyzed. All results of simulation showed that trapped-oil pressure and trapped-oil stiffness had greater impact on vibration characteristics of gears in external spur-gear pump, trapped-oil stiffness could reduce the vibration of the gears; in simulation of trapped-oil pressure, dynamic trapped-oil model related to dynamic characteristics of gears more accurate than the static trapped-oil model irrelated to dynamic characteristics of gears; the trapped-oil pressures in two trapped-oil cavity were different, the vibration characteristics of gears was better that in larger backlash value, etc.. Finally, by the trapped-oil stiffness of the external gear pump is unique, the important conclusions are educed that the vibration of gears in external spur-gear pump is indeed different from conventional gears and so on.

• Periodical: Applied Mechanics and Materials (Volumes 130-134)
• Pages: 610-615
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.130-134.610
• Online since: October 2011
• Authors: Yu Long Li, Kun Liu, Fu Chun Sun
• Keywords: Dynamic Model, External Spur-Gear Pump, Trapped-Oil Pressure, Trapped-Oil Stiffness
