Four-Point Regulation Algorithm for an End-Effector of a Flexible Drilling Robot

Abstract:

A new four-point algorithm for orientation and position regulation of an end-effector for a flexible drilling robot is presented in this paper．Four non-coplanar points in three-dimensional space can determine a unique sphere tangent to them, we can find out this sphere’s center point and radii and regard the shape of a workpiece surface in machining area approximately as such a sphere. A vector from the machining point to the center point is regarded as the one normal to the workpiece surface. By this principle, the algorithm firstly measured and calculated a vector normal to drilling machining area on curved surface by four points，and then calculated the difference between this normal vector and the axis of the spindle. If there is difference, the algorithm further figures out the angles of two revolving axes on end-effector and the displacements of three linear axes on robot main body, which should be adjusted．Simulation results of two kinds of curved surface show that the accuracy and efficiency satisfy the practical requirements using this algorithm．

• Periodical: Applied Mechanics and Materials (Volume 141)
• Pages: 298-302
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.141.298
• Online since: November 2011
• Authors: Lai Xi Zhang, Xing Song Wang
• Keywords: Drilling Machining, End Effector, Flexible Drilling Robot, Four-Point Position Regulation

References

[1] Alison Millar, Henrik Kihlman, Reconfigurable flexible tooling for aerospace wing assembly. 2009 SAE International.

DOI: 10.4271/2009-01-3243

[2] Zhou Wanyong, Zou Fang et al., Research on automatic drill with five axes for flexible assembly of aircraft wing components, Aeronautical Manufacturing Technology, 2 (2010) 44 - 46.

[3] Scott Hogan, John Hartmann et al., Automated wing drilling system for the A380-GRAWDE. 2003 SAE International.

DOI: 10.4271/2003-01-2940

[4] Joe Atkinson, John Hartmann et al., Robotic drilling system for 737 Aileron. 2007 SAE International.

[5] Benjamen Hempstead, PE Brent Thayer et al., Composite automatic wing drilling equipment (CAWDE). 2006 SAE Interna- tional.

DOI: 10.4271/2006-01-3162

[6] Jim Buttrick, Flex track drill. 2003 Aerospace Congress and Exhibition.

[7] Du Baorui, Feng Ziming et al., Robot drilling system for automatic drilling of aircraft component, Aeronautical Manufactur- ing Tech- nology, 2 (2010) 47 - 50.

[8] Paul Thompson, John Hartmann et al., Flex track for use in production. 2005 SAE International.

[9] Russell DeVlieg, Kevin Sitton et al., ONCE (ONe-sided Cell End-effector) robotic drilling system. 2001 Society of Automotive Engineers, Inc.

DOI: 10.4271/2002-01-2626

[10] Qin Xiansheng, Wang Wendan et al., Three-point bracket regulation algorithm for drilling and riveting of aerofoil, Acta Aeronautica et Astronautica Sinica, 28(2007) : 1455 - 1460.
