Vehicle Frame Fatigue Life Prediction Based on Finite Element and Multi-Body Dynamic

Abstract:

To accurately predict the fatigue life of vehicle frame, MBS and FEM were integrated. A full multi-body dynamic model was established first, according to the spectrum of road surface which simulate the china’s pavement condition, loading history at 11 critical positions was calculated. Then the stresses influence coefficient was calculated in finite element model which establish in ANSYS. At the same time, according to the frame material’s S-N curve and character of the frame, the frame’s S-N curve was received. Finally, based quasi-static stress analysis, the frame structure’s fatigue life was predicted by using MSC-FATIGUE. The fatigue analysis results were reasonable and could be the foundation for the research about lightening the structure of the frame.

• Periodical: Applied Mechanics and Materials (Volume 141)
• Pages: 578-585
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.141.578
• Online since: November 2011
• Authors: Si Hong Zhu, Zhi Jin Xiao, Xiao Yan Li
• Keywords: Fatigue Life, Finite Element Method (FEM), Multibody Dynamics (MBD), Road Spectrum, Vehicle Frame

References

[1] J. Z. Chu , J.Y. Wang : J . China Mechanical Engineering Vol.11 (1998), pp.1-2.

[2] Sr. Srikantan, S. Yerrapalli and H. Keshtkar: J .International Journal of Vehicle Design Vol.23 (2000), pp.95-108.

[3] S. Kyrre et al: Norwegian University of Science and Technology, Norwegian, 2002.

[4] M. F. LIN et al: J. Automotive Engineering Vol.13(1991), pp.235-242.

[5] L.Y.SUN, Z. H. Lu: J. Automotive Engineering Vol.23 (2001), pp.389-391.

[6] R.H.TAN, Y. Chen and Y.X. Lu: J. China Journal Of Highway And Transport Vol.11(1998) pp.96-101.

[7] P. Michelberger , L. Palkovics , J.Bokor: J .Vehicle Design Vol.14 (1993), pp.145-165.

[8] Z. S. Yu: Automobile Theory (Machinery Industry Press, Beijing 2002)

[9] H.X. Zhang et al: J. Automotive Engineering (1986), pp.21-31.

[10] M. Li et al: Automobile Structure Fatigue Design (Chinese Science and Technology University Press, He Fei 1995)

[11] P. J. Heyes: J. China Mechanical Engineering (1998), pp.13-15.

[12] National Bureau of Statistics of China, China Statistics Yearbook, China, 2006.

[13] M. Yu , J. H. Zhao , H. L. Wu: J. Automotive Engineering Vol.12(1990), pp.22-30.
