Simulation and Control of Two Side Direction Burr

Abstract:

A finite element model was developed for simulation of two side direction burr formation process. Based on strain distribution, a two side burr formation mechanism was proposed. Burr form and burr size of simulation are close to that's of experiment. Finite element model generated here provided a numerical analysis method to solve the prediction of burr and chip formation and physical insight into the fundamental burr formation mechanism. The stain in two side direction of material near the side face decides the shape and the size of two side direction. Multi-workpieces are machined at the same time with side face closely by each others can control the formation of two side direction strain and two side direction burr.

• Periodical: Applied Mechanics and Materials (Volumes 143-144)
• Pages: 428-432
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.143-144.428
• Online since: December 2011
• Authors: Hai Jun Qu, J.H. Yang, Gui Cheng Wang
• Keywords: Burr Control, Finite Element Model (FEM), Two Side Direction Burr, Two Side Direction Strain

References

[1] G.C. Wang. Metal cutting burrs. [M] Jilin: Jilin Press of science and technology, 1997. 11(in Chinese).

[2] G.C. Wang, C.G. Shen, H.J. Pei, et al. Formation and Control of Two Side Direction Burr [J] Advanced Materials Research, 2007, 24-25: 39-44.

DOI: 10.4028/www.scientific.net/amr.24-25.39

[3] Y.M. Zhu. Study on Formation and controlling of Metal cutting Burr and Development of Burr Expert System [D]. Zhenjiang: Jiangsu University. 2006(in Chinese).

[4] G.C. Wang. Study on two side direction burr formation in orthogonal cutting [J]. Journal of basic science and engineering, 1997, 5(3): 276-281(in Chinese).

[5] H.J. Qu, G.C. Wang, Y.M. Zhu et al. Simulation of two side direction burr formation. 2010 International Conference on Digital Manufacturing & Automation: 379-382.

DOI: 10.1109/icdma.2010.220

[6] G.C. Wang Y.M. Zhu C.Y. Zhang. Mathematical model of two side direction burr formation[J] Acta armamentaria, 2003, 24(4): 513-515 (in Chinese).

[7] K. Nakayama, M. Arai. Burr Formation in Metal Cutting [J]. Annals of the CRIP, 1987, 36 (1): 33-36.

DOI: 10.1016/s0007-8506(07)62547-5

[8] S.T. Fan. Burrs formation mechanism of precision turning. [D] Zhenjiang: Jiangsu university of science and technology, 1997(in Chinese).

[9] H.J. Qu, G.C. Wang, H.J. Pei, et al. Formation and Simulation of Cutting-direction Burr in Orthogonal Cutting [J]. Advanced Materials Research, 2007, 24-25: 249-254.

DOI: 10.4028/www.scientific.net/amr.24-25.249

[10] H.J. Qu, G.C. Wang, Y.M. Zhu, et al. Formation and simulation of Two Side Direction Burr in orthogonal cutting [J]. Advanced Materials Research, 2008, 53-54: 77-84.

DOI: 10.4028/www.scientific.net/amr.53-54.77

[11] Z.D. Zhao L.J. Yao R.Q. Pen G.C. Wang. Handbook of Copper and copper alloy [M]. Beijing: Press of science and technology, 1993(in Chinese).

[12] M. G. Cockroft: Determination of workpice flow stress and friction at chip-tool contact for high-speed cutting. International Journal of Machine Tools & Manufacture. (2000), P. 133~152.

DOI: 10.1016/s0890-6955(99)00051-6

[13] N. N. Zorev: Inter-relationship between shear processes occurring along tool face and shear plane in metal cutting, Proceedings of International Research in Production Engineering, ASME, New York. (1963), P42~49.
