Conjugate Heat Transfer Analysis and Design Optimization of Internally Cooling Turbine Blade

Abstract:

To improve the cooling efficiency of turbine blade, a multidisciplinary design optimization (MDO) system involving aerodynamics, heat transfer and structures has been developed. In this system, a MDO procedure for a turbine blade with complicate internal structure is performed. The structural size of rib turbulators, partitions and trailing edge cooling slots, which serve as design variables, is used for parametric modeling of three dimensional turbine blade. Conjugate heat transfer analysis is employed to get the temperature of the blade. The temperature in the blade body obtained from former coupled analysis is specified as boundary conditions for structural analysis. Meanwhile, a combined algorithm of multi-island genetic algorithm (MIGA) and sequential quadratic programming (SQP) is applied for optimization in specified space. While the flow rate of cooling air remains unchanged, the maximum and average temperatures of the blade decrease under the condition of meeting the strength requirement. The result shows that the cooling efficiency of turbine blade is improved, and the system exhibits higher stability, feasibility and efficiency for engineering applications.

• Periodical: Applied Mechanics and Materials (Volumes 148-149)
• Pages: 862-867
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.148-149.862
• Online since: December 2011
• Authors: Mao Hua Qu, Su Ya Sun, Ping Xi
• Keywords: Conjugate Heat Transfer, Cooling Blade, Design Optimization, Temperature

References

[1] M. Eifel, V. Caspary, H. Hönen and P. Jeschke: Experimental and numerical analysis of gas turbine blades with different internal cooling geometries, ASME J. Turbomach, Vol. 133 (2011), Issue 1, 011018, DOI: 10. 1115/1. 4000541.

DOI: 10.1115/1.4000541

[2] S.S. Talya, A. Chattopadhyay and J.N. Rajadas: Multidisciplinary design optimization procedure for improved design of a cooled gas turbine blade, Engineering Optimization, Vol. 34 (2002), No. 2, pp.175-194.

DOI: 10.1080/03052150210917

[3] K Yu, X Yang: Aerodynamic and heat transfer design optimization of internally cooling turbine blade based different surrogate models, Structural and Multidisciplinary Optimization, Vol. 44(2010), No. 1, pp.75-83.

DOI: 10.1007/s00158-010-0583-x

[4] G. Nowak and W. Wróblewski: Application of conjugate heat transfer for cooling optimization of a turbine airfoil, ASME Turbo Expo: Power for Land, Sea, and Air, Orlando, Florida, USA (2009), No. GT2009-59818, pp.715-724.

[5] M. Yang, B. Liu and J. Li et al.: China Aeronautical Materials Handbook, Wrought superalloys, Cast superalloys , 2nd Ed, Vol. 2, (Standards Press of China, Beijing 2002).

[6] S.S. Thakur, J.A. Wright and W. Shyy: Convective film cooling over a representative turbine blade leading-edge, Int. J. Heat Mass Transfer, Vol. 42 (1999), p.2269–2285.

DOI: 10.1016/s0017-9310(98)00124-0

[7] V.K. Sivashanmugam, M. Arabnia and W. Ghaly: Aero-structural optimization of an axial turbine stage in three-dimensional flow, ASME Turbo Expo: Power for Land, Sea, and Air, Glasgow, UK (2010), No. GT2010-23406, pp.967-980.

DOI: 10.1115/gt2010-23406
