Structure of Mold Surface for Stress Relaxation Forming of Integral Panel of 2124 Aluminum Alloy

Abstract:

This paper proposed a method and process of stress relaxation forming based on initial geometric springback compensation-finite element optimization-revision by experiment iteration. Obtained material parameters of 2124 aluminum alloy by a series of foundation craft experiments; springback law on the structure of 2124 aluminum alloy by foundation experiment of autoclave forming of T test specimens, that use to compensate the mold surface with the geometric springback. The precision of the geometric springback compensation of the mold surface is about 3 mm; while after the finite element iteration optimization on the mold surface with the initial geometric springback compensation, the deviation of that between the testing date and the theory appearance of specimens can reach the magnitude about ±1.2 mm. Next use the mold “frequency domain” revision algorithm based on experiment iteration to revise local mold surface of the stress relaxation forming. The testing date shows the precision control in ±0.5 mm that satisfied with the application of engineering.

• Periodical: Applied Mechanics and Materials (Volumes 152-154)
• Pages: 140-144
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.152-154.140
• Online since: January 2012
• Authors: Zhong Gan, Yu Ping Wu, Jia Zan Zhu, Hai Bing Tan
• Keywords: Finite Element Optimization, Geometric Springback Compensation, Mold Revision among Frequency Domain, Stress Relaxation Forming

References

[1] Xinshen Sun. Reseach on approximate expansion of non-expandable curve and internal structure mapping [D]. Northwestern Polytechnical University. (2004).

[2] Denise M. Hambrick. Age Forming Technology Expanded in an Autoclave [C]. SAE Transaction, 1985. 94.

[3] Zhong Gan, Haiyan Zhang, Tianxiu Wang. Research on application of creep constitutive model in age-forming simulation [J]. Journal of System Simulation. 2009, 20(21): 6647-6649.

[4] Xia Huang, Yuansong Zeng, Shuo Huang. Experimental research on the creep age forming for Al alloy 2324 [J], Journal of Plasticity Engineering. 2009, 16(3): 136-139.

[5] Lin Huang, Min Wan, Shuo Huang. FEM analysis of creep age forming of 7B04 Al alloy thickness panel [J], Precision Sheet Metal Forming Technology. 2007, Supplement: 484-487.

[6] Zhong Gan, Lei Zhang. Research on springback compensation of mold surface for age forming of integral panel [J], Journal of Plasticity Engineering. 2010, 17(5): 15-18.

[7] Holman, M C. Autoclave age forming large Al aircraft panels [J]. Journal of Mechanical Working Technology. 1989. 20: 477-488.

DOI: 10.1016/0378-3804(89)90055-7

[8] Karafillis A P, Boyce M C. Tooling design in sheet metal forming using springback calculations, International Journal of Mechanical Sciences, 1992, 34 (2): 113～131.

DOI: 10.1016/0020-7403(92)90077-t

[9] Webb. R. D. and Hardt. D. E.: Transfer function description of sheet metal forming for process control, Journal of Engineering for industry, 1991, 33(2): 44-52.

DOI: 10.1115/1.2899621

[10] Hindman C, Ousterhout K B, Developing a flexible sheet forming system. Journal of Materials Processing Technology , 2000 , 9: 38～48.

DOI: 10.1016/s0924-0136(99)00257-5
