Investigation on the Effect of Infilled Walls Utilizing Response Spectrum Analysis for Steel Staggered-Truss System

Abstract:

Considering the structure type of the steel staggered-truss (SST) system, the effect of infilled walls will be major and need to be studied amply, some scientific design regulations need to be found for referrence. Based on two different 3D models considering or ignoring the stiffness of infilled walls (SIW), a numerical investigation is presented on the structural behaviors of the SST system utilizing the finite element 3D simulation analysis soft ware ETABS. The longitudinal structure is asymmetrical due to the SIW, it causes the torsion forces in the building. Comparing to the different results of response spectrum analysis, including storey drift and equivalent base shear under frequent earth quake and rare earth quake, some conclusions were made, including the capacity of the SST system under seismic load and the effect of the SIW for SST system. The increased base shear force factors due to the effect of the SIW were suggested for SST structure design, it is different from the other steel structure types.

• Periodical: Applied Mechanics and Materials (Volumes 152-154)
• Pages: 34-39
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.152-154.34
• Online since: January 2012
• Authors: Qing Sheng Guo, Qing Shan Yang
• Keywords: Capacity of Anti-Seismic Load, Response Spectrum Analysis, Shear Force Increase Factor, Steel Staggered-Truss System, Stiffness of Infilled Walls

References

[1] Kim, J. H. Lee, Y. M. Kim, Inelastic Behavior of Staggered Truss Systems, Structural Design of Tall and Special Buildings, Vol. 16, (2007), pp.85-105.

DOI: 10.1002/tal.361

[2] X. H. Zhou, T. Mo, Y. J. Liu, Z. M. Yin, L. F. Lu, Q. S. Zhou, Experimental Study on High-rise Staggered Truss Steel Structure, Journal of Building Structures (in Chinese), Vol. 27 (2006), pp.86-92.

[3] H. P. Bakke, L. A. Kloiber, A. C. Nuhn. Staggered Truss Building Systems, Civil Engineering ASCE , Vol. 39 (1969) pp.56-59.

[4] A. E. Hassler, Erecting the Staggered Truss System: a View From the Field, Engineering Journal AISC, Vol. 23 (1986) pp.166-172.

[5] A. I. Socrates, D. L. Stanley, Staggered Truss Adapted to High Rise, Civil Engineering ASCE, Vol. 80 (1985) pp.44-47.

[6] GB50017-2003 Code for Design of Steel Structure(in Chinese).

[7] JGJ12-99 - Code for Design Light Weight Aggregate Concrete Stuctures (in Chinese).

[8] GB50011-2010 - Code for Seismic Design of Building (in Chinese).
