The Visual Extraction of the Autonomous Lawnmower Navigation Route

Abstract:

This paper uses the more intuitive visual processing of the camera to extract navigation information instead of using the low-end information collection technology of the photoelectric sensor as the current autonomous lawnmower navigation sensor. Image grey processing, binary algorithm, the image smooth method, the image inflation, the improved Hough transform combining with VC++ are used to get the line in order to distinguish the done and undone lawn successfully and to obtain navigation path and navigation parameters. The improved grayscale algorithm and the Hough transform algorithm have reduced the amount of image data processing, solved the small angle lines problem, and improved the real-time of the robots. Meanwhile prove the impossibility of image sharpening and border detection on extracting lawn boundary. The feasibility of the lawn image processing has been proved by examples.

• Periodical: Applied Mechanics and Materials (Volumes 157-158)
• Pages: 1458-1464
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.157-158.1458
• Online since: February 2012
• Authors: Li Si Fu, Yong You Xing
• Keywords: Autonomous Lawnmower, Hough Transform (HT), Image Processing, Robot Navigation

References

[1] Huang Yu-qing, and Liang Ming. Path Planning Algorithms of Robots Navigation System[J], , Microcomputer Information Control &Automation, 2006, vol. 22(7), pp.259-261.

[2] XIN Jiang-hui, LI Shun-ming, and LIAO Qing-bin. Review on autonomous mobile robots navigation based on sensors information[J], Sensor and Micro Systems, 2008, vol. 27(4), pp.4-7.

[3] Gao Shou-chuan, and Yao Ling-tian. Visual c + + practice and improve - digital image processing and engineering application articles[M], BeiJing: China Railway Press, 2006, pp.1-4.

[4] CONG Ming, and JIN Li-gang, and FANG Bo. Intelligent Robot Mowers: A Review[J], Robot, 2007, vol. 29(4) , pp.407-416.

[5] Anon The 3rd Annual On Autonomous Lawnmower Competition [EB/OL]. http: /www. automow/, 2006-06-01.

[6] Smith J, Campbell S, and Morton J. Design and implementation of a control algorithm for an autonomous lawnmower[A], Proceedings of the IEEE International Conference on Circuit and Systems. Piscataway, NJ, USA: IEEE, 2005, pp.456-459.

[7] Wu Wen-qi, and SUN Zeng-qi. Overview of Camera Calibration Mothods for Machine Vision[J], Application Research Of Computers, 2004, (2) , pp.4-6.

[8] Zhou Jin-he, and Peng Fu-tian. A Method of Selective Image Greying[J], Computer Engineering, 2006, vol. 32(20) , pp.198-199.

[9] Xu Ya-ming. Infrared image binarization based on edge detect[J], Modern Instruments, 2008(2) , pp.34-35.

[10] Yu Guo-ying, and Mao Han-ping. Study on Visual Navigation Parameter Dertermination of Agricultural Vehicle[J], Agricultural Mechanization Research, 2007, (1) , pp.167-168.

[11] Kang Tao. The Research and Design of Detection System based on the Image Processing[M], "Xi, an Science and Technology University, 2005, pp.18-20.

[12] Li Xiao-fei, Ma Da-wei, and Nian Yong-jian. The Research on Algorithm of Image's Erosion and Dilation[J], Video Techniques, 2005(1) , pp.37-39.

[13] Wang Zheng-yao, and Cheng Zheng-xing. The Edge Detection of Digital Image [D], "Xi, an Jiaotong Uiversity, 2003, pp.16-5.
