Dial Instrument Calibration by both Automatic and Half-Automatic Methods

Abstract:

This paper presents a calibration system by video processing technique. The system can calibrate large number of different types of dial instruments. The system is composed of an automatic recog-nition approach and a half-automatic approach. Both the automatic calibration and half-automatic calibration include four steps: 1st, dial plane circle edge extraction and center identification; 2nd, pointer extraction; 3rd, scale start and end position identification; 4th, result reading. For half-automatic method, the 1st step and 3rd step are manually indentified. By experiments and practical application in industry, it proves that our calibration system is effective for more than hundreds of different types of dial instruments.

• Periodical: Applied Mechanics and Materials (Volumes 157-158)
• Pages: 581-588
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.157-158.581
• Online since: February 2012
• Authors: Zhen Long Bai, Xiang Li
• Keywords: Calibration System, Dial Instrument, Pointer Extraction

References

[1] R. Sablatnig W.G. Kropatsch, Application constraints in the research of an automatic reading device for analog display instruments. Applications of Computer Vision(1994). p.205 ~212.

DOI: 10.1109/acv.1994.341310

[2] F. Correa Alegria, A. Cruz Serra. Automatic calibration of analog and digital measuring instruments using computer vision. IEEE Transactions on Instruments and Measurement(2000), 49(1). p.94~99.

DOI: 10.1109/19.836317

[3] Jinhui LAN, Xiangqin WEI, Zhenlong BAI, Automatic calibration system for analog instruments based on DSP and CCD sensor, International Conference of Optical Instrument and Technology, (2008), pp.151-160.

DOI: 10.1117/12.810962

[4] C.R. Halkyard. Maximum likelihood estimation of flexural wavenumbers in lightly damped plates. Journal of Sound and Vibration (2007), Vol. 300, p.217–240.

DOI: 10.1016/j.jsv.2006.08.019

[5] Shihai GAO, Shaoping ZHAO. Application of computer vision in automatic instrument metrology and calibration. Computer Standards and Interfaces (1998), Vol. 21(2), p.23~28.

DOI: 10.1016/s0920-5489(99)92255-9

[6] F. Galliana, P.P. Capra. A new automatic reference and switching unit for calibration of high value resistors in the range 100 kV to 10 TV. Measurement (2001), Vol. 29, p.269–277.

DOI: 10.1016/s0263-2241(00)00046-4

[7] Lyndon N. Smisth, Melvyn L. Smith, Automatic machine vision calibration using statistical and neural network methods, Image Vision Computing (2005), Vol. 23, p.887~899.

DOI: 10.1016/j.imavis.2005.03.009
