Research on Pressure Characteristics of Vehicle Air Braking System with Leakage from Pipeline

Abstract:

Based on the vehicle air braking system circuit analysis, a pressure characteristics model in the states of normalcy and leakage was built, and the relationship between brake pressure characteristics and leakage was studied. Based on the modeling and study, simulation was done using the MATLAB; On the other hand, experimental setup of vehicle air braking system was designed, and the experiments were carried. Then the simulation results were compared with experimental results. By comparison and analysis, we come to a conclusion that the model in this paper can accurately describe the pressure characteristics of vehicle air braking system.

• Periodical: Applied Mechanics and Materials (Volumes 157-158)
• Pages: 608-611
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.157-158.608
• Online since: February 2012
• Authors: Zhi Shen Wang, Gang Yan Li, Qi Qiao Wu, Jun Xu
• Keywords: Air Braking System, Modeling, Pressure Characteristics, Simulation

References

[1] Z.S. WANG, G.Y. LI, Modeling and Research on the Air Brake System of Automobile with ABS. Machine Tool & Hydraulics (2009).

[2] R. B. GmbH., Automotive Brake Systems. Society of Automotive Engineers (SAE), Warrendale, PA (1995).

[3] Batchelor G.K. Introduction to Fluid Dynamics(2nd edition). Cambridge University (2000).

[4] S. Subramanian, S. Darbha, and K. Rajagopal, Modeling the Pneumatic subsystem of an S-cam air brake system, Journal of Dynamic Systems, Measurement, and Control, (2004).

DOI: 10.1115/1.1666893

[5] S. C. Subramanian, A diagnostic system for air brakes in commercial vehicles, Ph.D. dissertation, Texas A&M University, College Station, Texas, (2006).
