Response of Shallow-Buried Circular Lining Tunnel to Incident PWave

Abstract:

Taking the circular lining tunnel in half-space as prototype, this paper investigates the dynamic responses of this tunnel. A series solution for the scatting waves in half-space and the lining is derived by wave expansion method under the assumption of the large circular arc. And then, combining the boundary conditions, the tunnel dynamic response is shift to seeking the solution of series of algebraic equations. Finally, the effects of buried depth, lining rigidity and incident frequency upon the dynamic hoop stress in the inner lining surface caused by incident plane Pwave is quantitatively analyzed from the view of theory in a typical case.

• Periodical: Applied Mechanics and Materials (Volume 160)
• Pages: 331-336
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.160.331
• Online since: March 2012
• Authors: Y.S. Li, T.B. Li, X Zhang
• Keywords: Circular Lining Tunnel, Dynamic Hoop Stress Concentration Factor, Dynamic Response, Plane PWave

References

[1] C.H. Dowding, A. Rozen. Damage to rock tunnels from earthquake shaking[J], Journal of the Geotechnical Engineering Division, ASCE, Vol. 104(1): 175-191.

DOI: 10.1061/ajgeb6.0000580

[2] W.L. Wang, Z.J. Su, J.H. Lin, et al. Discussion on damaged extent of mountainous tunnels due to Jiji earthquake in Taiwan[J]. Modern Tunnelling Technology, 2001, Vol. 38(2): 52-60(In Chinese).

[3] Y.H. Pao, C.C. Mow. Diffraction of elastic waves and dynamic stress concentrations [M]. New York: Crane Russak and Company, (1973).

[4] V.W. Lee, M.D. Trifunac. Response of tunnels to incident SH-waves [J]. Journal of Engineering Mechanics, American Society of Civil Engineering, 1979, 105: 643-659.

DOI: 10.1061/jmcea3.0002511

[5] V.W. Lee, J. Karl. On deformation of near a circular underground cavity subjected to incident plane Pwaves [J]. European Journal of Earthquake Engineering, 1993, (1): 29-36.

[6] C.A. Davis, V.W. Lee, J.P. Bardet. Transverse response of underground cavities and pipes to incident SV waves [J]. Earthquake Engineering and Structural Dynamics, 2001, 30: 383-410.

DOI: 10.1002/eqe.14

[7] J.W. Liang, H. Zhang. A series solution for surface motion amplify-effection due to underground group cavities incident Pwaves[J]. Acta Seismologica Sinica, 2004, Vol. 26(3): 269-280(In Chinese).

DOI: 10.1007/s11589-004-0052-y

[8] G.D. Shao, W.H. Luo. An investigation on aseismic behaviors of railway tunnel lining during strong earthquake[J]. China Railway Science, 1992, Vol. 12(2): 92–108(In Chinese).
