An Experimental Study to Determine the Optimal Sizes for Ball-Valve Micropump Channel

Abstract:

The geometrical configurations of ball-valve micropumps have great influence on its efficiency. In particular, the ball valve channels have great influence on the efficiency of ball-valve micropumps because the prevention of backflow directly affects the performance of ball-valve micropumps.This study used water to investigate the optimal size of channels for piezoelectric ball-valve micropumps. The results show that the optimal angle for micro ball valve seats is 30°. The piezoelectric film vibrates rapidly and the back pressure in the water outlet channel is higher than it in the water inlet channel . This phenomenon indicates that channels are optimal sizes for a distance of 0 mm in the water inlet channel and 0.3mm in the water outlet channel.

• Periodical: Applied Mechanics and Materials (Volume 163)
• Pages: 100-106
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.163.100
• Online since: April 2012
• Authors: Ming Hsun Wu, Chien Mu Lai
• Keywords: Ball Valve, Micropumps

References

[1] Esashi M, Shoji S, and Nakano A ~1989, Normally closed microvalve and micropump fabricated on a silicon wafer, Sens. Actuators 20, 163–169.

DOI: 10.1016/0250-6874(89)87114-8

[2] Feng G-H and Kim E S 2004 Micropump based on PZT unimorph and one-way parylene valves J. Micromech. Microeng. 14 429–35.

DOI: 10.1088/0960-1317/14/4/001

[3] Krusemark O, Feustel A and Muller J Micro ball valve for fluidic micropumps and gases Proc, Micro Total Analysis Systems, 98 Workshop p.399–402, (1998).

DOI: 10.1007/978-94-011-5286-0_95

[4] Oh K W, Rong R and Ahn C H In-line micro ball valve through polymer tubing Proc, microTAS 2001 p.407–8, (2001).

DOI: 10.1007/978-94-010-1015-3_179

[5] Fu C, Rummler Z and Chomburg W Magnetically driven micro ball valves fabricated by multilayer adhesive film bonding J, Micromech, Microeng, (2003).

DOI: 10.1088/0960-1317/13/4/316

[6] Christophe Yamahata, Fr´ed´eric Lacharme, Yves Burri, Martin A.M. Gijs, A ball valve micropump in glass fabricated by powder blasting, Sensors and Actuators B, Ver. 110, p.1–7, (2005).

DOI: 10.1016/j.snb.2005.01.005

[7] Carrozza MC, Croce N, Magnani B, and Dario P ~1995, A piezoelectric-driven stereolithography-fabricated micropump, J. Micromech. Microeng. 5, 177–179.

DOI: 10.1088/0960-1317/5/2/032

[8] Tingrui Pan, Scott J McDonald, Eleanor M Kai1 and Babak Ziaie, A magnetically driven PDMS micropump with ball check-valves, J. Micromech. Microeng, pp.1021-1026, (2005).

DOI: 10.1088/0960-1317/15/5/018

[9] Ahn, S. H. & Kim, Y. K., Fabrication and experiment of a planar micro ion drag pump, Sensors and Actuators A, vol. 70, pp.1-5, (1998).

DOI: 10.1016/s0924-4247(98)00105-8

[10] Tsai, J. & Lin, L., A thermal-bubble-actuated micronozzle-diffuser pump. pdf, Journal of Microelectromechanical Systems, vol. 11, pp.665-671, (2002).

DOI: 10.1109/jmems.2002.802909
