Dynamic Analysis of Extendible Support Structure Deployment

Abstract:

To study the dynamic behavior of the extendible support structure deployment, a digital simulation using the multibody system dynamics methodology is conducted. Floating frame of reference formulations are used to establish the flexible dynamics model, in which the deformation vector of each flexible part is modeled with the component mode synthesis technique based on the Craig-Bampton method. Modal truncation is implemented through modal participation factors to reduce the computational burden. Angular displacements results of antenna panels as well as those of truss rods are then obtained and show that all parts of the structure have reached accurate positions and keep stable after deployment as expected. Start torque of the driving motor is also acquired and proved acceptable according to the design requirements. Impact forces acting on the hinges at locking moment are finally extracted to evaluate performances of locking processes.

You might also be interested in these eBooks

History of Mechanical Technology and Mechanical Design 2012

View Preview

Info:

Periodical:

Applied Mechanics and Materials (Volume 163)

Pages:

91-94

DOI:

https://doi.org/10.4028/www.scientific.net/AMM.163.91

Citation:

Cite this paper

Online since:

April 2012

Authors:

Shun Guang Song, Chun Jie Wang, Han Wang, Qiu Hong Lin

Keywords:

Component Mode Synthesis, Deployment, Extendible Support Structure, Flexible Multibody Dynamics, Modal Truncation

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] W.D.R. Thomas: Canadian Journal of Remote Sensing, Vol. 30 (2004) No. 3, pp.282-286.

Google Scholar

[2] Y. Shen, S. Montminy, and W. Zheng, et al: 48th AIAA/ASME/ASCE/AHS/ASC Structures, Structural Dynamics, and Materials Conference (Hawaii, U. S., April 23-26, 2007). Vol. 8, pp.7639-7649.

DOI: 10.2514/msdm07

Google Scholar

[3] A. A. Shabana: Multibody System Dynamics , Vol. 1 (1997) No. 2, pp.189-222.

Google Scholar

[4] R. R. Craig JR. and M. C. C. Bampton: AIAA Journal, Vol. 6 (1968) No. 7, pp.1313-1319.

Google Scholar

[5] O. Wallrapp and S. Wiedemann. Multibody System Dynamics , Vol. 7 (2002) No. 1, pp.101-125.

Google Scholar

[6] E. W. Gao, X. P. Zhang and Z. Q. Yao: Journal of Shanghai Jiaotong University, Vol. 13 (2008) No. 3, pp.275-279.

Google Scholar

[7] F. F. Birhanu, Z. B. Chen and W. S. Ma: Information Technology Journal, Vol. 9 (2010) No. 3, pp.600-604.

Google Scholar
