Experimental Study of Pile Foundation Dynamic Testing Used in the Anchor Rod Nondestructive Testing

Abstract:

The dynamic testing of stress wave reflection method is an easy, economical, rapid and reliable nondestructive testing technology and has been perfected used in the pile foundation dynamic testing. Anchor rod is more in line with the wave theory of one-dimensional elastic rod than pile foundation whether to theory or the geometric solid, material, stress state and other factors. The quality of anchor rod is determined by using small strain method (hammering method) of pile foundation dynamic measurement. Four testing anchor rods with different length and integrity were made in project of "China Marine Sport School", stress wave time domain curve of anchor rod was obtained by ZK-7E portable intelligent testing of piles instrument, defect location, length of anchor rod and integrity reflected by measured waveform are consistent with the actual situation, the method using pile foundation dynamic testing technology for anchor rod nondestructive testing is proved feasible and reliable.

• Periodical: Applied Mechanics and Materials (Volumes 166-169)
• Pages: 559-562
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.166-169.559
• Online since: May 2012
• Authors: Li Wei Zhang, Wei Shi, Yu Na Zou, De Sheng Zhu
• Keywords: Anchor Rod, Experimental Study, Method of Stress Wave, Nondestructive Testing (NDT), Pile Foundation Dynamic Testing

References

[1] Guowei Zhu, Suping Peng, Huaixiu Wang. Experimental study of detection dense anchoring situation of high frequency stress wave．Soil and rock mechanics, 2002,23(6) in Chinese

[2] A. Kilic, E. Yasar, C.D. Atis, Effect of bar shape on the pull-out capacity of fully-grouted . Tunnelling and Underground Space Technology 2003,18: 1-6

DOI: 10.1016/s0886-7798(02)00077-9

[3] B.N. Pavlakovic,M d .S.Lowe,and P. Cawley,High frequency low loss ultrasonic modes in imbedded bars,Journal of Applied Mechanics,2001,68:67—7

DOI: 10.1115/1.1347995

[4] Dailin Xia. Nondestructive testing technique of anchoring quality rapid [Master Dissertation]．Jiaozuo：Faculty of Engineering of Jiaozuo. in Chinese.

[5] Liwei Zhang. The study and application of deep foundation pit shotcrete and rock bolt support stress wave nondestructive testing theory.Master Dissertation of Qingdao Technological University.2007 (6). in Chinese
