Deformation-Based Nonlinear Finite Element Analysis of Steel High Performance Concrete Structural Walls

Abstract:

Base on the experiment results of steel high performance reinforced concrete (SHPRC) structural walls, nonlinear finite element(FE) analysis is performed to simulate the complete process of the loading and concrete crack of SHPRC structural walls in the platform of ABAQUS. The nonlinear of material is taken into account in the models. The reliability of the finite element model is verified through the comparison of the analysis results and the experimental results. Based on the proposed model, the parametric analysis is carried out to study the effect of axial load ratio, aspect ratio, stirrup characteristic value, and steel ratio on the seismic behavior of SHPRC structural walls. It is concluded that the bearing capacity of SHPRC structural walls increase with the increase of the axial load ratio, but the deformation decreases obviously. The deformation and bearing capacity of the structural walls are improved by increasing the steel ratio. With increasing the stirrup characteristic value, the deformation of the structural walls improves significantly. The stirrup characteristic values are proposed to ensure the SHPRC structural walls for different axial load ratios meet the deformation capacity of drift ratio of 1/120,1/100 and 1/80, respectively.

• Periodical: Applied Mechanics and Materials (Volumes 166-169)
• Pages: 797-802
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.166-169.797
• Online since: May 2012
• Authors: Ma Kaize
• Keywords: Bearing Capacity, Deformation, Finite Element, Steel High Performance Reinforced Concrete Structural Walls, Stirrup Characteristic Values

References

[1] ABAQUS.(2006). ABAQUS Theory Manual. Hibbitt,Karlsson and Sorensen Inc

[2] Bai L. (2009). Experiment Research and Design Theory of Steel High Performance ConcreteStructural Walls. PhD Dissertation, Xi'an University of Architecture and Technology, China. (in Chinese)

[3] GB50010-2001, Code for design of concrete structure. Beijing: Chinese architecture industry Press; 2002. (in Chinese)

[4] GB50011-2001, Code for seismic design of buildings. Beijing: Chinese Architecture Industry Press; 2002. (in Chinese)

[5] Guan P. Wang Q.X. Zhao G.F. (1998). Study on the Tests of Stress-Strain Relationship of Confined High Strength Concrete Industrial Construction, 1997 27:11, 26-29. (in Chinese)

[6] Guo Z. H. (2004). Reinforced Concrete Theory and Analyses. Beijing: Tshinghua university press. (in Chinese)

[7] Lee J, and Fenves G.L. (1998). Plastic-Damage Model for Cyclic Loading of Concrete Structures. Journal of Engineering Mechanics, 124, (8):892-900.

DOI: 10.1061/(asce)0733-9399(1998)124:8(892)

[8] Lubliner J. Oliver J. and Oller S. (1989). A Plastic-Damage Model for Concrete. International journal for Solids and Structures, 25:299-399.

DOI: 10.1016/0020-7683(89)90050-4
