Experimental Study on Vertical Base-Isolated System with Disk Spring

Abstract:

A new vertical isolator designed by disk spring, called combined disk spring bearing (DSB), is introduced in this paper. DSB is composed of one main disk spring bearing and eight secondary disk spring bearings. Performance tests show that DSB had good property of variable vertical stiffness and high vertical damping. Then, the effectiveness of DSB vertical base-isolated devices in reducing structural responses caused by earthquakes through a series of 1/2 scale shaking table tests. are conducted to study the seismic responses of the and the DSB vertical-isolated system. Compared with the fixed-base system, experimental results show that the DSB vertical-isolated system can isolate vertical earthquake energy remarkably. Large displacement of the DSB vertical-isolated system occurred on the isolation layer, and the inter-story deformation of the superstructure changed slightly. The acceleration responses of DSB vertical-isolated system decreased more than 50% and the displacement responses decreased more than 40% at 0.4g PGA, which confirmed that DSB could decrease the seismic responses effectively.

• Periodical: Applied Mechanics and Materials (Volumes 166-169)
• Pages: 788-792
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.166-169.788
• Online since: May 2012
• Authors: Yamin Zhao*, Jingyu Su, Ming Lu
• Keywords: Disk Spring, Experimental Study, Vertical Isolation

References

[1] J.M. Kelly. Base Isolation: Origins and Development, EERC News, Vol. 12(1) (1991), pp.130-140

[2] F. Naeim and J. M. Kelly. Design of Seismic Isolated Structures-From Theory to Practice (John Willy &Sons, INC, New York 1999)

[3] J. M. Asher, S. N. Hoskere, R. D. Ewing. Seismic Performance of the Base-isolated USC University Hospital in the 1994 Northridge Earthquake, Proceedings of Pressure Vessels and Piping Conference, Seismic Shock and Vibration Isolation. Vol. 319(1995), pp.147-154.

[4] J. J. Bommer, S. Akkar, and Özkan Kale. A Model for Vertical-to-Horizontal Response Spectral Ratios for Europe and the Middle East. Bulletin of the Seismological of America, Vol. 101(4) (2011), pp.1783-1806

DOI: 10.1785/0120100285

[5] M. Niazi, and Y. Bozorgnia. Behavior of Near-source Vertical and Horizontal Response Spectra at Smart-1 Array, Taiwan. Earthquake Engineering and Structural Dynamics, Vol. 21(1992), pp.37-50

DOI: 10.1002/eqe.4290210103

[6] N. N. Ambraseys, J. Douglas. Near-field Horizontal and Vertical Earthquake Ground Motions. Soil Dynamics and Earthquake Engineering. Vol.23 (2003), p.1–18

DOI: 10.1016/s0267-7261(02)00153-7

[7] T. Shimada, T. Fujiwaka, and S. Moro. Study on Three-dimensional Seismic Isolation System for Next-Generation Nuclear Power Plant: Hydraulic Three-dimensional Base Isolation System. Proceedings of Pressure Vessels and Piping Conference, ASME. USA: San Diego, California. Vol.486 (2004), pp.35-42.

DOI: 10.1115/pvp2004-2931

[8] A. Kashiwazaki, R. Mita, and T. Enomoto, et al. Three-dimensional Base Isolation System Equipped with Hydraulic Mechanism. Transactions of the Japan Society of Mechanical Engineers, Vol.66 (1999), pp.146-151.

DOI: 10.1299/kikaic.66.2616

[9] K. Inoue, M. Morishita, and T. Fujita. Development of Three-dimensional Seismic Isolation Technology for Next Generation Nuclear Power Plant in Japan. Proceedings of Pressure Vessels and Piping Conference, ASME. USA: San Diego, California. Vol.486 (2004), pp.29-34.

DOI: 10.1115/pvp2004-2930

[10] J. O. Almen, A.Laszlo. The Uniform-section Disc Spring. Transactions of ASME, 58(RP-58-10), (1936), pp.305-314.

DOI: 10.1115/1.4020233
