Simulation Study of the Hydraulic System of Concrete Pumping Truck Based on AMESim

Abstract:

The working principle of concrete pumping hydraulic system was analyzed. And base on the AMESim software, the complete simulation model of concrete pumping hydraulic system was built. A simulation was made to get the dynamic characteristics curve of hydraulic cylinder velocity and displacement at some specific conditions. The simulation results indicate that the model is reasonable. Comparative simulations of the pumping hydraulic system with different positions of buffer structure were carried out to study the relationship between buffer effect and the buffer position which can be used to provide theory basis for deeper study of the hydraulic shock.

• Periodical: Applied Mechanics and Materials (Volumes 170-173)
• Pages: 1920-1925
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.170-173.1920
• Online since: May 2012
• Authors: Chang Ge Fan, Fa Lin Zeng, De Hua Li, Lei Liu
• Keywords: AMEsim, Concrete Pumping Truck, Hydraulic System, Simulation

References

[1] Falin ZENG, Lei LIU, Chao WANG. Simulation of the Buffer Device in Pumping Hydraulic System of the Concrete Pump Truck Based on AMESim[J]. The 2010 International Conference on Information, Electronic and Computer Science, 2010.11.

[2] Falin ZENG, Lei LIU, Chao WANG: Machine Tool& Hydraulic,2011(13),pp.110-113

[3] LIU Lei ZENG Fa-ling HUANG Bao-lei CHANG E LI De-hua : Hydraulics Pneumatics & Seals;2011(04),pp.17-20.

[4] Yan Zhan-hui1,WANG Chun-bo2: Chinese Hydraulics & Pneumatics,2010-04,pp.35-40

[5] LIU Tingli, HU Guoqing:Machine :Tool & Hydraulics,2008(04),pp.27-31

[6] Xiaoqian YANG: Simulation Study of the Hydraulic System of Concrete Pumping Truck,2003(4).In Chinese.
