Design of OTA-C Gaussian Function Generator

Abstract:

A novel method for analogue VLSI implementation of programmable Gaussian function generator is proposed in this paper, in which the Gaussian function is approximated by the OTA-C filter whose frequency response is Gaussian-shaped. OTA-C circuit is very suitable for this application since the programmability can be controlled by the transconductance of OTA precisely and easily. Based on the probability argument, the OTA-C biquadratic filters and OTA-C integrator which have the cascade connection are used as the building block. To elaborate the construction procedure, a seventh-order OTA-C Gaussian function generator is selected as an example. The simulation results verify the feasibility of the presented approach.

• Periodical: Applied Mechanics and Materials (Volumes 182-183)
• Pages: 690-694
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.182-183.690
• Online since: June 2012
• Authors: Kun Gao
• Keywords: Filter Synthesis, Gaussian Function, OTA-C Filter, Signal Processing

References

[1] S. Mallat: A Wavelet Tour of Signal Processing (Academic Press, New York 2001).

[2] H.C. Card, D. K. Mcneill and C. R. Schneider: Analog Int. Circuits and Signal Processing. No. 15 (1998), p.291.

[3] L. Yingwei, N. Sundararajan and P. Saratchandran: IEEE Trans. Neural Networks. Vol. 9 (1998), p.308.

[4] S. Churcher, A. F. Murray and H. M. Reekie: Electron. Lett. vol. 29 (1993), p.1603.

[5] G. Marshall and S. Collins: Analog Int. Circuits and Signal Processing. No. 11 (1996), p.21.

[6] W.S. Zhao, Y.G. He, J.Y. Huang, S.Z. Qi and G.F. Fang: Proc. ICWAPR. (2007), p.756.

[7] R.L. Geiger and E. Sanchez-Sinencio: Proc. IEEE. (1985), p.20.

[8] W. McC: Circuits, Signal, and Systems (The MIT Press, Cambridge MA 1986).
