The Application of Flash Memory in Computerized Jacquard Controller

Abstract:

Through analyzing the pattern data of computerized jacquard knitting wrap machine, comparing the current storages structure and type, this paper introduces a method for Flash file structure of jacquard data. The method takes advantage of ARM chip to achieve the operations for access and modification of Flash, designing a management procedures of jacquard data access from the perspective of increasing the Flash life. The management procedures not only complete read and write operations, but also meet the requirement of jacquard high-speed data transfer.

• Periodical: Applied Mechanics and Materials (Volumes 182-183)
• Pages: 706-710
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.182-183.706
• Online since: June 2012
• Authors: Cheng Jun Zhang, Xiao Yan Zuo, Chi Zhang, Xiao Guang Wu
• Keywords: Address Mapping, Computerized Jacquard, FLASH, Pattern Data, STM32

References

[1] Dazhang You. Computerized jacquard CAD/CAM system design. Knitting Indestry, 2006. 3: pp.12-14.

[2] Pengzhe Han. FLASH memory application in the power data collection terminal., Automation & Instrumentation, 2009. 1: pp.58-59, 98.

[3] Hang Yan. FAT file system improved design on NAND Flash memory. Signal Chip and Embedded System, 2006. 11: pp.27-29.

[4] Gang Wang, Pinpin Guan, etc. The study of extend the life of Flash memory. Signal Chip and Embedded System, 2009. 11: 69-70.

[5] Chi Zhang, Jiangang Zhang, etc. Key technology in embedded control system of jacquard knitting. 2010 International Conference on Mechatronics and Automation (ICMA), 2010: pp.129-132.

DOI: 10.1109/icma.2010.5588022
