The Multi-Objective Optimization of the Planet Carrier in Wind Turbine Gearbox

Abstract:

In order to improve the reliability of a planet carrier, a simulation method based on multi-objective design optimization was developed in this paper. The objective of the method was to reduce the stress concentration, the deformation, and the quality of the planet carrier by optimizing the structure dimension. A parametric finite element model, which enables a good understanding of how the parameters affect the reliability of planet carrier, was established and simulated by ANSYS-WORKBENCH. The efficiency of the design optimization was improved by using a polynomials response surface to approximate the results of finite element analysis and a screening algorithm to determine the direction of optimization. Furthermore, the multi-objective optimization was capable of finding the global minimum results in the use of the minimum principle on the response surface. Computer simulation was carried out to verify the validity of the presented optimization method, by which the quality and the stability of the planet carrier were significantly reduced and improved, respectively. The methodology described in this paper can be effectively used to improve the reliability of planet carrier.

• Periodical: Applied Mechanics and Materials (Volumes 184-185)
• Pages: 565-569
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.184-185.565
• Online since: June 2012
• Authors: Peng Xing Yi, Li Jian Dong, Yuan Xin Chen
• Keywords: Finite Element Analysis (FEA), Multi-Objective Optimization (MOP), Planet Carrier, Polynomials Response Surface
