Design of Intelligent Winding Machine for Tassel Thread Based on Stepping Motor

Abstract:

On account of the end splitting and dropping thread problem for domestic winding machine during tassel thread production process at present, an intelligent system with subdivision driving module TB6560AHQ and SANYO stepping motor was designed, which adopted the ATMEL89S52 MCU as the core controller. The system achieved precise control of some parameters during the course of tassel thread winding such as torque, direction of rotation, speed, cycle laps, twist, etc. It also reduced the worker’s labour intensity and improved the production quality and efficiency of the tassel manufacturing, moreover, this winding machine has the advantages of simple structure, high torque, high reliability and low cost. It can meet the various control requirements for different tassel thread winding and have a considerable market prospect.

• Periodical: Applied Mechanics and Materials (Volume 189)
• Pages: 317-320
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.189.317
• Online since: July 2012
• Authors: Hong Shen, Feng Shao, Jun Peng Xu
• Keywords: ATMEL89S52 MCU, Stepping Motor, Subdivision Driving, Tassel Thread, Winding Machine
