The Effect of Structural Geometric Nonlinearities on the Flutter of the Straight and Swept Wing Configurations

Abstract:

High altitude and long endurance (HALE) vehicle always adopt straight or swept configuration, which leads to the problem that the wings of UAV have high aspect ratio and are very flexible. This kind of flexible wing exhibits large deformation when aerodynamic forces are loaded on them and the structural nonlinearity should be considered. So the dynamic and flutter characteristics will be changed. In the engineering applications, the effects of structural geometric nonlinearities on the air vehicle design are the most concerns of aeroelasticity before a systematic flutter analysis for the air vehicle. because the solution for nonlinear flutter speed based on the CFD-CSD method is complex and time consuming. In this paper, we propose a simple and efficient approach that can analyze the effect of structural geometric nonlinearities on the flutter characteristics of high aspect ratio wing quickly. And a straight wing and a straight-swept wing are analyzed to verify the feasibility and efficiency of the proposed method. It is found that the effect of structural geometric nonlinearities has a strong effect on the flutter characteristic of the straight wing, but is weak on the straight-swept wing. And finally the impact of swept angle on the dynamic and flutter characteristics of straight-swept wing is also discussed.

• Periodical: Applied Mechanics and Materials (Volume 189)
• Pages: 306-311
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.189.306
• Online since: July 2012
• Authors: Qing Guo, Bi Feng Song
• Keywords: Aeroelasticity, Flexible Wing, Large Deformation, Structural Nonlinearity

References

[1] Mayuresh J. Patil, Dewey H. Hodges, On the importance of Aerodynamic and Structural Geometrical Nonlinearities in Aeroelastic Behavior of High-Aspect-Ratio Wings, AIAA-2000-1448.

DOI: 10.2514/6.2000-1448

[2] Song Tianxia, Guo Jianshe, Yang Yuanming, Nonlinear Solid Computational Mechanics, (2005).

[3] Mayuresh J. Patil, Dewey H. Hodges, Nonlinear aeroelasticity and flight dynamics of high-altitude long endurance aircraft, AIAA-99-1470.

DOI: 10.2514/6.1999-1470

[4] YongHui Zhao, Aeroelasticity and control, science press, (2007).
