Stress and Displacement Analysis with Multiple Loads

Abstract:

This paper analyses the stress and the displacement with multiple loads by the structure of the linear static. Use the static solver provided by UG NX Nastran; get the parameters of the stress and the displacement of the component with some kinds of loads. Not only get the result for each subcase, but also for any subcase in the combined quickly. It provides facilitation for comparison and analysis of each subcase and the combined case on some calculation results.

• Periodical: Applied Mechanics and Materials (Volumes 190-191)
• Pages: 1266-1268
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.190-191.1266
• Online since: July 2012
• Authors: Dong Liang Zhang, Bin Wu Wang, Fei Liu
• Keywords: Displacement, Finite Element, Multiple Loads, Stress

References

[1] Li Chunliang; Application of the essence of real case NX CAE; Publishing House of electronics industry;2009.11

[2] Zhu chonggao. The base and examples of UG NX CAE, Tsinghua University press;2010.10

[3] Xia Yongxu. The semi analytic method of nonlinear bending and stability about the axisymmetric shallow conical shell. [J];Joural of Chang'an University (Natural Science Edition); 1990(04)

[4] Liu Li. Liu Tuguang. Li Tao. Li Tianjun. The elastic plastic dynamic bucking study about the cylindrical shell under the action of complex load. [Journal Papers] –Explosion and shock.2002(2)

[5] Yin WL. The effects of laminated structure on delamination buckling and growth. Journal of mposite Materials [J]. 1988.

[6] Shen Chungen. Wang Guicheng. The example of finite element analysis by UG NX 7, Machinery Industry Press;2010.07
