Test and Study of Soybean Storage Anti-Grading Device

Abstract:

Automatic classification of grain warehousing is a long-standing problem, particularly for soybean. Automatic classification of soybean brought a series of questions such as warehousing, discharging, storage and processing. To solve these problems, we analyzed the status quo of anti-grading technology and device at home and abroad, and proposed an anti-grading device that consisted of warehousing distributor and multi-channel feeding tube. We changed the traditional single-point discharge to a more coordinated discharge, and reduced the work of topping barn and the phenomenon of grain gradation. From the tests and analysis of single-tube and multi-tube inside and outside warehouse repeatedly, we confirmed the reasonable parameters, and acquired practical achievement of the anti-grading of soybean storage. It has some practical application value.

• Periodical: Applied Mechanics and Materials (Volume 192)
• Pages: 46-50
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.192.46
• Online since: July 2012
• Authors: Fu Cai Yuan, Zhen Qing Wang, Hai Min Han, Yong Wang
• Keywords: Anti-Grading, Soybean, Squat Silos, Test

References

[1] Y.C. Wang, W.G. Yao and J.W. Li: The Cause Analysis of Automatic Classification of Grain in Squat Silos and the Resolution [J], Grain Distribution Technology, Vol. 6 (2010) No. 3, p.28.

[2] Y.S. Jiang: Comparison of some Storage Device on Squat Soil [J], Cereal & Feed Industry, Vol. 9 (2009) No. 9, p.16.

[3] Z.M. Qiao, G.C. Li, B.X. Wang, X.J. Xu, R. Zhang, L. Wang, X.L. Chen, J. Hu, G.M. Zhang and P. Zhao: Application of Multi-function Decompression Duct in Soil and Squat Soil [J], Grain Storage, (2007) No. 4, p.31.

[4] L.L. Zhang, A.Q. Zhang, Y. Zhu and J.F. LI: Types of Automatic Classification of Grain and Prevention [J], Grain Distribution Technology, Vol. 12 (2008) No. 6, p.28.

[5] F. Yuan, F.M. Wang: Study of Calculation Methods for Wall Pressure of Granular Materials in Squat Silos [J], Journal of Dalian University of Technology, (2006) No. 1, p.39.

[6] F. Yuan, H. Wang, Y.X. Hu and S.S. Zhang: A General Method for Silo Classification Using Rupture Plane[J], Journal of Southeast University (English Edition), （2009）No. 3, p.18.

[7] K.C. Li, S.C. Zheng: A Storage Device of the Automatic Anti-grading of Grain [P] Chinese. Patent 200920051315. 3. (2009).

[8] Z.Q. Wang, L. Fan and Y.M. Hou: A Warehouse Building of Mechanized Bulk Grain [P] Chinese Patent 200920276151. 4. (2010).

[9] M. Zhang, F.Y. Zhou: The Science of Grain Storage, (Science Press, Chinese2010).

[10] Z.Q. Wang, Y. Wang, etc: Experimental Study of Soybean Warehousing Distributor [D] (Henan University of Technology 2010).
